M521 AUDITORY ASSISTANCE TRANSMITTER Block Diagram - FCC ID B5DM521

FCC ID B5DM521

BLOCK DIAGRAM

AUDITORY ASSISTANCE TRANSMITTER

by Bosch Security Systems, Inc.

Document preview loads when visible.

Document Details

FCC IDB5DM521
Document ID452504
Document TypeBlock Diagram
DescriptionBLOCK DIAGRAM
Document Title\PST170BK
ApplicantBosch Security Systems, Inc.
Equipment ClassAUDITORY ASSISTANCE TRANSMITTER
Product CodeM521
Application IDqIm6fUWJXSMs06JMAMNdvA==
Application PurposeOriginal Equipment
Application Date2004-07-22
Frequency Range72.1-75.9 MHz
FRN0020258489
Test FirmTimco Engineering, Inc.
Certified ByCHARLIE CONNER
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-07-22
Available2004-07-22
Created2004-06-03
Modified2004-06-03
Pages1
File TypeAdobe Acrobat PDF
File Size4673
File SHA-2560bcdecf0be8726b1a848bc169a2bc4a1e119b2cc2f298bcabd428697f0417944
PDF Metadata ProducerTango Schematic V1.50 Acrobat Distiller 5.0 (Windows)
FCC.gov SourcesFCC.gov 452504
