TN0036A Car Audio Label Diagram - FCC ID BABTN0036A

FCC ID BABTN0036A

06 Label and Location

Car Audio

by DENSO TEN Limited

Document preview loads when visible.

Document Details

FCC IDBABTN0036A
Document ID6966526
Document TypeID Label/Location Info
Description06 Label and Location
Document TitleTN0036A_Label_Image_Label_Position_Ver.1.2u
ApplicantDENSO TEN Limited
Equipment ClassCar Audio
Product CodeTN0036A
Application IDlfd77hwpCzqIUjB/q0amTg==
Application PurposeOriginal Equipment
Application Date2023-12-06
Frequency Range5765 MHz
FRN0008516007
Test FirmUL Japan, Inc.(Ise)
Certified ByYukari Ito Senior Project Coordinator
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date06/03/2024
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2023-12-05
Available2023-12-06
Created2023-08-31
Modified2023-08-31
Pages1
File TypeAdobe Acrobat PDF
File Size229931
File SHA-256e1aedb3532a07e98188d0e85bdd47e86fe4c2112e14e5b1be7c1c8628bdcb892
PDF Metadata Author00004323
PDF Metadata ProduceriText® Core 8.0.0 (AGPL version) ©2000-2023 Apryse Group NV
FCC.gov SourcesFCC.gov 6966526, FCC.gov 6966450, FCC.gov 6966336
