SATBAS Wireless Telephone Headset... - FCC ID BCE-SAT-BAS

FCC ID BCE-SAT-BAS

Page 4

Wireless Telephone Headset Transceiver

by GN Audio USA Inc.

Page 4

Document Details

FCC IDBCE-SAT-BAS
Document ID8151
Document TypeSchematics
DescriptionPage 4
ApplicantGN Audio USA Inc.
Equipment ClassWireless Telephone Headset Transceiver
Product CodeSATBAS
Application IDMRe+aEH1AQFUyo9ICas/sg==
Application PurposeOriginal Equipment
Application Date1998-11-24
Frequency Range925.409-926.57 MHz
FRN0005875158
Certified ByMichael Violette President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted1998-09-27
Available1998-11-24
Pages0
File TypeJPEG Image
File Size1177086
File SHA-256b0bc2ed336bf5520d5124e63e4d0c4865fb847fe64cda72632bd4ea2bb7e7fb1
FCC.gov SourcesFCC.gov 8151
