FCC ID BEJLC7FR
Faceplate RADIO ASM-RECEIVER
by LG Electronics USA
Grantee Code: BEJ Product Code: LC7FR
Latest application date: 2016-11-11
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Class II permissive change or modification of presently authorized equipment | 2016-11-11 |
| 2402-2480 MHz | Original Equipment | 2016-05-17 |
| 2412-2462 MHz | Original Equipment | 2016-05-17 |
| 5180-5240 MHz | Original Equipment | 2016-05-17 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-11-10 | PDF 271.4 KB |
| Internal Photos | Internal Photos | 2016-11-10 | PDF 859.9 KB |
| External Photos | External Photos | 2016-11-10 | PDF 1.4 MB |
| ID Label and Location Info | ID Label/Location Info | 2016-05-17 | PDF 108 KB |
| Test Setup Photos | Test Setup Photos | 2017-05-05 | PDF 838.7 KB |
| Test Setup Photos | Test Setup Photos | 2016-11-10 | PDF 704.3 KB |
| RF Test Report - UNII | Test Report | 2016-11-11 | PDF 2 MB |
| RF Test Report -UNII -Rev2 | Test Report | 2016-05-17 | PDF 2.8 MB |
| Test Report - DSS | Test Report | 2016-05-17 | PDF 4.3 MB |
| Test Report - DTS | Test Report | 2016-05-17 | PDF 3 MB |
| Test Report - NII | Test Report | 2016-05-17 | PDF 2.8 MB |
| C2PC Application Letter | Cover Letter(s) | 2016-11-11 | PDF 12.9 KB |
| Confidential Request Letter | Cover Letter(s) | 2016-11-11 | PDF 42.4 KB |
| Confidential Request Letter | Cover Letter(s) | 2016-05-17 | PDF 59.3 KB |
| Declaration for non-US channel operation | Cover Letter(s) | 2016-05-17 | PDF 68.5 KB |
| RF Exposure Info | RF Exposure Info | 2016-05-17 | PDF 130.6 KB |
| Block Diagram Metadata only | Block Diagram | PDF 18.6 KB | |
| Schematics Metadata only | Schematics | PDF 2 MB | |
| OP - Antenna Spec Metadata only | Operational Description | PDF 51 KB | |
| OP - KDB 594280 Software Security documentation Metadata only | Operational Description | PDF 88 KB | |
| Operational Description Metadata only | Operational Description | PDF 577.5 KB | |
| Operational Description Metadata only | Operational Description | PDF 520.1 KB | |
| Operational Description - Antenna spec Metadata only | Operational Description | PDF 51 KB | |
| Operational Description - Software Security Metadata only | Operational Description | PDF 47.8 KB | |
| Part List Metadata only | Parts List/Tune Up Info | PDF 141 KB |
Application Information
| Application ID | jznlFoJkNh+jSWxa9ZRMwA== |
|---|---|
| Final Action Date | 2016-11-11 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0023476120 |
| Model | LC7FR |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | Faceplate RADIO ASM-RECEIVER |
| Responsible Party | Sung Soo Kim, Director, Regulatory and Environmental Affairs, sungsoo.kim@lge.com  , 201-266-2215 |
| Test Firm | Sang Lee, HCT Co., LTD, sjlee@HCT.co.kr  , 82-31-645-6420 |
| TCB Email | tcb@hctamerica.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 05/05/2017 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | C2PC Approval. Power listed is the peak conducted output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. End-users must be provided with transmitter operation conditions for satisfying RF exposure compliance requirements. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. This device operates with 20MHz channel bandwidth capabilities. |
