NT17Z90Q Notebook Computer Test Setup Photos - FCC ID BEJNT-17Z90Q

FCC ID BEJNT-17Z90Q

TempConfidential_Test Setup Photo-DSS

Notebook Computer

by LG Electronics USA

Document preview loads when visible.

Document Details

FCC IDBEJNT-17Z90Q
Document ID5981900
Document TypeTest Setup Photos
DescriptionTempConfidential_Test Setup Photo-DSS
ApplicantLG Electronics USA
Equipment ClassNotebook Computer
Product CodeNT17Z90Q
Application IDpQZ8/cw1ZbZMRU5F09HvfQ==
Application PurposeClass II Permissive Change
Application Date2022-07-21
Frequency Range2402-2480 MHz
FRN0023476120
Test FirmAudix Technology Corporation
Certified ByBen Cheng
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date10/31/2022
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2022-07-07
Available2022-10-31
Created2022-06-15
Modified2022-06-15
Pages3
File TypeAdobe Acrobat PDF
File Size620664
File SHA-25696e45b4010404a53362ae307616680da76f68adf5b8afe3012ce25a1d13475da
PDF Metadata Authortina_huang
PDF Metadata Producertina_huang Microsoft® Word 2010
FCC.gov SourcesFCC.gov 5981900
