TLVLM3IUE Telematics Test Setup Photos - FCC ID BEJTLVLM3IU-E
FCC ID BEJTLVLM3IU-E
Test Setup Photos
Telematics
Document preview loads when visible.
Document Details
| FCC ID | BEJTLVLM3IU-E |
|---|---|
| Document ID | 4185344 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | Test Photo(PCB)_TLVLM3IU-E |
| Applicant | LG Electronics USA |
| Equipment Class | Telematics |
| Product Code | TLVLM3IUE |
| Application ID | FUzDDzQOUET0INRjf9kESg== |
| Application Purpose | Original Equipment |
| Application Date | 2019-02-28 |
| Frequency Range | 2505-2565 MHz |
| FRN | 0023476120 |
| Test Firm | DT&C; Co., Ltd. |
| Certified By | Harvey Sung Technical Director, DT&C; Co., Ltd. |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 08/27/2019 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2019-02-28 |
| Available | 2019-08-27 |
| Created | 2019-02-28 |
| Modified | 2019-02-28 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 477813 |
| File SHA-256 | 79f8da42e1e609224e9561b4e252225e9308fddbf86b5446d40f918b41b96b8a |
| PDF Metadata Author | jhahn |
| PDF Metadata Producer | jhahn Acrobat Distiller 11.0 (Windows) |
| FCC.gov Sources | FCC.gov 4185344 |
