WB1NP7 Bluetooth Module Test Setup Photos - FCC ID BEJ-WB1NP7

FCC ID BEJ-WB1NP7

Test setup photos

Bluetooth Module

by LG Electronics USA

Document preview loads when visible.

Document Details

FCC IDBEJ-WB1NP7
Document ID3263382
Document TypeTest Setup Photos
DescriptionTest setup photos
ApplicantLG Electronics USA
Equipment ClassBluetooth Module
Product CodeWB1NP7
Application IDQtB/orNrqGNOo946X0xdrQ==
Application PurposeOriginal Equipment
Application Date2017-01-18
Frequency Range2402-2480 MHz
FRN0023476120
Test FirmSGS KOREA CO., Ltd.
Certified ByKyung-Su Han
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/17/2017
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2017-01-18
Available2017-07-17
Created2017-01-13
Modified2017-01-13
Pages6
File TypeAdobe Acrobat PDF
File Size344917
File SHA-256f2d31a106db50ff93cd74a5128840d926e9dc7b6d162fc19f20886717807fb4e
PDF Metadata AuthorWIN98
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 3263382
