X147XG Microwave Oven Schematics - FCC ID BEJX147XG

FCC ID BEJX147XG

Schematics

Microwave Oven

by LG Electronics USA

Document preview loads when visible.

Document Details

FCC IDBEJX147XG
Document ID352568
Document TypeSchematics
DescriptionSchematics
Document TitleBEJX147XG_Block_diagram .PDF
ApplicantLG Electronics USA
Equipment ClassMicrowave Oven
Product CodeX147XG
Application IDqu+MQeWaAOhzaLyh6dWJXg==
Application PurposeClass II Permissive Change
Application Date2003-09-03
Frequency Range2450 MHz
FRN0020917688
Test FirmLG Electronics Inc.
Certified ByRandy Ortanez President
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-09-03
Available2003-09-03
Created2003-08-26
Modified2003-08-27
Pages1
File TypeAdobe Acrobat PDF
File Size26649
File SHA-2564df8abf6ad820b1b37d8da257eb942e1e91083a0f1b24f9e4b40db281d311432
PDF Metadata Authorkwangmu
PDF Metadata ProducerAcrobat PDFWriter 4.0 for Windows NT kwangmu
FCC.gov SourcesFCC.gov 352568
