Q700MS1 MS-700 Teardown Internal Photos - FCC ID BFDQ700MS1
FCC ID BFDQ700MS1
internal photos
MS-700
Document preview loads when visible.
Document Details
| FCC ID | BFDQ700MS1 |
|---|---|
| Document ID | 159348 |
| Document Type | Internal Photos |
| Description | internal photos |
| Document Title | MAIN BOARD BACK AND BOTTOM OF PS |
| Applicant | Clear-Com Intercom Systems |
| Equipment Class | MS-700 |
| Product Code | Q700MS1 |
| Application ID | ANrZsWZ4eReUUIjbtxlbfQ== |
| Application Purpose | Original Equipment |
| Application Date | 2001-07-11 |
| Frequency Range | 470-740 MHz |
| FRN | 9999999999 |
| Test Firm | TUV America |
| Certified By | Judy Evans Technical Writer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2001-07-11 |
| Available | 2001-07-11 |
| Created | 2001-07-09 |
| Modified | 2001-07-09 |
| Pages | 15 |
| File Type | Adobe Acrobat PDF |
| File Size | 349223 |
| File SHA-256 | 0ba2cb5d9a958c74e6e2a2aac7b891c58867dccbba76ddafd1b86c7974ef407b |
| PDF Metadata Author | Judy Evans |
| PDF Metadata Producer | Acrobat Distiller 4.05 for Windows Microsoft Word 8.0 |
| FCC.gov Sources | FCC.gov 159348 |
