MA 302MHz Alarm Receiver Block Diagram - FCC ID BGAMA

FCC ID BGAMA

Block Diagram

302MHz Alarm Receiver

by Audiovox Corporation

Block Diagram

Document Details

FCC IDBGAMA
Document ID106431
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantAudiovox Corporation
Equipment Class302MHz Alarm Receiver
Product CodeMA
Application IDo9KPPjjmzBXXwqDGKxG6OQ==
Application PurposeOriginal Equipment
Application Date2000-06-15
Frequency Range302 MHz
FRN0007714579
Test FirmCompliance Certification Services Inc
Certified ByTom Cokenias Director of Engineering
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2000-06-23
Available2000-06-15
Pages0
File TypeJPEG Image
File Size570226
File SHA-256e83aaca925e8fec97df274f53f52880a30c5eec23df07d609ac152e00a011323
FCC.gov SourcesFCC.gov 106431
