CP9000DW Digital Color Printer Test Setup... - FCC ID BGBCP9000DW
FCC ID BGBCP9000DW
Setup photos
Digital Color Printer
Document preview loads when visible.
Document Details
| FCC ID | BGBCP9000DW |
|---|---|
| Document ID | 364250 |
| Document Type | Test Setup Photos |
| Description | Setup photos |
| Document Title | 24AE0055-HO-1_FCC15C_ |
| Applicant | Mitsubishi Electric Corp |
| Equipment Class | Digital Color Printer |
| Product Code | CP9000DW |
| Application ID | +cWnWsqTSjq1eQESYTEiGg== |
| Application Purpose | Original Equipment |
| Application Date | 2003-10-09 |
| Frequency Range | 13.56 MHz |
| FRN | 0009565698 |
| Test Firm | UL Apex Co., Ltd. |
| Certified By | Tetsuya Hashimoto Site Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-10-09 |
| Available | 2003-10-09 |
| Created | 2003-09-29 |
| Modified | 2003-09-29 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 382120 |
| File SHA-256 | ebead71046cd71dd8ba3e8944452402cf5befd1e6f252aa6d7cb814c6cdeb2ab |
| PDF Metadata Author | 40640 |
| PDF Metadata Producer | 24AE0055-HO-1(FCC15C) - Microsoft Word Acrobat PDFWriter 5.0 for Windows NT |
| FCC.gov Sources | FCC.gov 364250 |
