60WRC02TX 6002TX Remote Control... - FCC ID BJ4-60WRC02TX
FCC ID BJ4-60WRC02TX
Schematic
6002TX Remote Control Transmitter
by HeathCo LLC
Document preview loads when visible.
Document Details
| FCC ID | BJ4-60WRC02TX |
|---|---|
| Document ID | 337194 |
| Document Type | Schematics |
| Description | Schematic |
| Document Title | P-CAD EDA - [Sheet1] |
| Applicant | HeathCo LLC |
| Equipment Class | 6002TX Remote Control Transmitter |
| Product Code | 60WRC02TX |
| Application ID | wCbcNipLk0ZFB1mKfhHx4A== |
| Application Purpose | Original Equipment |
| Application Date | 2003-07-02 |
| Frequency Range | 315 MHz |
| FRN | 0023784812 |
| Test Firm | Nemko Canada Inc. |
| Certified By | Jeff Bessinger |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-07-02 |
| Available | 2003-07-02 |
| Created | 2003-06-10 |
| Modified | 2003-06-12 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 73454 |
| File SHA-256 | dbbaf61ab8f7ff2a7e733dc4a5ca025ed0aacedadc043fcc607dc29af2183128 |
| PDF Metadata Producer | AdobePS5.dll Version 5.2 Acrobat Distiller 5.0 (Windows) |
| FCC.gov Sources | FCC.gov 337194 |
