60WRC30TX 6030 Motion Sensor Schematics - FCC ID BJ4-60WRC30TX
FCC ID BJ4-60WRC30TX
New schematic
6030 Motion Sensor
by HeathCo LLC
Document preview loads when visible.
Document Details
| FCC ID | BJ4-60WRC30TX |
|---|---|
| Document ID | 456915 |
| Document Type | Schematics |
| Description | New schematic |
| Document Title | P-CAD EDA - [Sheet1] |
| Applicant | HeathCo LLC |
| Equipment Class | 6030 Motion Sensor |
| Product Code | 60WRC30TX |
| Application ID | aYrq1FHyqRIAlDTPFPGfAQ== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2004-08-05 |
| Frequency Range | 315 MHz |
| FRN | 0023784812 |
| Test Firm | Nemko Canada Inc. (Ottawa) |
| Certified By | Jeff Bessinger Associate Regulatory Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2004-08-05 |
| Available | 2004-08-05 |
| Created | 2004-06-24 |
| Modified | 2004-06-25 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 29491 |
| File SHA-256 | cf46e528bc13a4b28feb4916ef5550b99077597df75f2015464728d7e1a13e8a |
| PDF Metadata Author | wraper |
| PDF Metadata Producer | Acrobat PDFWriter 5.0 for Windows NT wraper |
| FCC.gov Sources | FCC.gov 456915 |
