Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 1 of 23
: April 19, 2018
: BKEHAC015
RADIO TEST REPORT
Test Report No. : 12208081S-C
Applicant
Nintendo Co., Ltd.
Type of Equipment
Wireless Game Device
Model No.
HAC-015
FCC ID
BKEHAC015
Test regulation
FCC Part 15 Subpart C: 2018
Test item
Radiated Spurious Emission
Test Result
Complied
1.
2.
3.
4.
5.
6.
This test report shall not be reproduced in full or partial, without the written approval of UL Japan, Inc.
The results in this report apply only to the sample tested.
This sample tested is in compliance with the above regulation.
The test results in this report are traceable to the national or international standards.
The opinions and the interpretations to the result of the description in this report are outside
scopes where UL Japan has been accredited.
This test report covers Radio technical requirements. It does not cover administrative issues
such as Manual or non-Radio test related Requirements. (if applicable)
Date of test:
March 15 to 21, 2018
Representative test
engineer:
Kazutaka Takeyama
Engineer
Consumer Technology Division
Approved by:
Akio Hayashi
Leader
Consumer Technology Division
The testing in which "Non-accreditation" is displayed is outside the accreditation scopes in UL Japan.
RTL02610
There is no testing item of "Non-accreditation".
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
13-EM-F0429
Test report No.
Page
Issued date
FCC ID
REVISION HISTORY
Original Test Report No.: 12208081S-C
Revision
- (Original)
Test report No.
12208081S-C
Date
April 19, 2018
Page revised
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Contents
: 12208081S-C
: 2 of 23
: April 19, 2018
: BKEHAC015
Test report No.
Page
Issued date
FCC ID
CONTENTS
: 12208081S-C
: 3 of 23
: April 19, 2018
: BKEHAC015
PAGE
SECTION 1: Customer information.......................................................................................................4
SECTION 2: Equipment under test (E.U.T.) .........................................................................................4
SECTION 3: Test specification, procedures & results..........................................................................5
SECTION 4: Operation of E.U.T. during testing ..................................................................................7
SECTION 5: Radiated Spurious Emission ............................................................................................8
APPENDIX 1: Test data ........................................................................................................................10
Radiated Spurious Emission ............................................................................................................. 10
APPENDIX 2: Test instruments ...........................................................................................................21
APPENDIX 3: Photographs of test setup .............................................................................................22
Radiated Spurious Emission ............................................................................................................. 22
Worst Case Position .......................................................................................................................... 23
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 4 of 23
: April 19, 2018
: BKEHAC015
SECTION 1: Customer information
Company Name
Address
Telephone Number
Facsimile Number
Contact Person
Nintendo Co., Ltd.
11-1 Hokotate-cho, Kamitoba, Minami-ku, Kyoto 601-8501, Japan
+81-75-662-9600
+81-75-662-9624
Kazuya Kuramoto
SECTION 2: Equipment under test (E.U.T.)
2.1
Identification of E.U.T.
Type of Equipment
Model No.
Serial No.
Rating
Receipt Date of Sample
Country of Mass-production
Condition of EUT
Modification of EUT
2.2
Wireless Game Device
HAC-015
Refer to Section 4, Clause 4.2
Vbat: DC 3.2 V to DC 4.5 V (Typical: DC 3.7 V)
Vin: DC 5.0 V
March 12, 2018
China
Production prototype
(Not for Sale: This sample is equivalent to mass-produced items.)
No Modification by the test lab
Product Description
Model: HAC-015 (referred to as the EUT in this report) is a Wireless Game Device.
Radio Specification
Bluetooth:
Radio Type
Frequency of Operation
Modulation
Power Supply (radio part input)
Antenna type
Antenna Gain
Operation temperature
Transceiver
2402 MHz - 2480 MHz
FHSS
DC 1.8 V
Inverted-F Antenna
0.54 dBi
+5 deg.C to +35 deg.C
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Test report No.
Page
Issued date
FCC ID
SECTION 3:
3.1
: 12208081S-C
: 5 of 23
: April 19, 2018
: BKEHAC015
Test specification, procedures & results
Test Specification
Test Specification
FCC Part 15 Subpart C
FCC Part 15 final revised on March 12, 2018 and effective April 11, 2018
Title
FCC 47CFR Part15 Radio Frequency Device Subpart C Intentional Radiators
Section 15.207 Conducted limits
Section 15.247 Operation within the bands 902-928 MHz,
2400-2483.5 MHz, and 5725-5850 MHz
* The revision on March 12, 2018, does not affect the test specification applied to the EUT.
3.2
Item *1)
Spurious
Emission &
Band Edge
Compliance
Procedures and results
Test Procedure
FCC: FCC Public Notice
DA 00-705
IC: RSS-Gen 6.13
Specification
FCC: Section15.247(d)
IC: RSS-247 5.5
RSS-Gen 8.9
RSS-Gen 8.10
Worst Margin
7.6 dB
12400.000 MHz, AV, Hori.
Tx 2480 MHz DH5
Results
Remarks
Conducted/
Complied
Radiated
(above 30 MHz)
*2)
Note: UL Japan, Inc.’s EMI Work Procedures No. 13-EM-W0420 and 13-EM-W0422.
*1) Regarding as other items, refer to the test report: 11257132S-A-R3.
*2) Radiated test was selected over 30 MHz based on section 15.247(d).
Conducted test was selected below 30 MHz. Refer to the test report: 11257132S-A-R3.
* In case any questions arise about test procedure, ANSI C63.10: 2013 is also referred.
FCC Part 15.31 (e)
The EUT is supplied the power from battery or host device.
In either method, the EUT provides stable voltage (DC 1.8 V) constantly to RF Module regardless of input voltage.
In the case of battery method, the test was performed with the full-charged battery.
Therefore, the EUT complies with the requirement.
FCC Part 15.203 Antenna requirement
The equipment and its antenna comply with the requirement since the antenna is built in the equipment and it cannot
be replaced by end users.
3.3
Addition to standard
No addition, exclusion nor deviation has been made from the standard.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Test report No.
Page
Issued date
FCC ID
3.4
: 12208081S-C
: 6 of 23
: April 19, 2018
: BKEHAC015
Uncertainty
EMI
The following uncertainties have been calculated to provide a confidence level of 95 % using a coverage factor k=2.
Shonan EMC Lab.
Item
Frequency range
Radiated emission
(Measurement distance: 3 m)
9 kHz-30 MHz
30 MHz-200 MHz
200 MHz-1 GHz
1 GHz-6 GHz
6 GHz-18 GHz
18 GHz-40 GHz
1 GHz-18 GHz
18 GHz-40 GHz
Radiated emission
(Measurement distance: 1 m)
SAC=Semi-Anechoic Chamber
SR= Shielded Room is applied besides radiated emission
No. 1 SAC / SR
3.2 dB
4.3 dB
5.9 dB
4.7 dB
5.3 dB
5.6 dB
5.6 dB
5.9 dB
No. 2 SAC / SR
3.2 dB
4.3 dB
5.9 dB
4.7 dB
5.3 dB
5.6 dB
5.6 dB
5.9 dB
Uncertainty (+/-)
No. 3 SAC / SR
3.3 dB
4.3 dB
5.9 dB
4.7 dB
5.3 dB
5.6 dB
5.6 dB
5.9 dB
No. 4 SAC / SR
Radiated emission test
The data listed in this test report has enough margin, more than the site margin.
3.5
Test Location
UL Japan, Inc. Shonan EM C Lab.
1-22-3, M egumigaoka, Hiratsuka-shi, Kanagawa-ken 259-1220 JAPAN
Telephone: +81 463 50 6400, Facsimile: +81 463 50 6401
JAB Accreditation No. RTL02610
FCC Test Firm Registration Number: 839876
Test site
No.1 Semi-anechoic
chamber
No.2 Semi-anechoic
chamber
No.3 Semi-anechoic
chamber
No.4 Semi-anechoic
chamber
No.1 Shielded room
No.2 Shielded room
No.3 Shielded room
No.4 Shielded room
No.5 Shielded room
No.6 Shielded room
No.8 shielded room
No.1 M easurement
room
3.6
IC Registration
Number
Width x Depth x
Height (m)
Size of reference ground plane (m) /
horizontal conducting plane
M aximum
measurement
distance
2973D-1
20.6 x 11.3 x 7.65
20.6 x 11.3
10 m
2973D-2
20.6 x 11.3 x 7.65
20.6 x 11.3
10 m
2973D-3
12.7 x 7.7 x 5.35
12.7 x 7.7
5m
8.1 x 5.1 x 3.55
8.1 x 5.1
6.8 x 4.1 x 2.7
6.8 x 4.1 x 2.7
6.3 x 4.7 x 2.7
4.4 x 4.7 x 2.7
7.8 x 6.4 x 2.7
7.8 x 6.4 x 2.7
3.45 x 5.5 x 2.4
6.8 x 4.1
6.8 x 4.1
6.3 x 4.7
4.4 x 4.7
7.8 x 6.4
7.8 x 6.4
3.45 x 5.5
2.55 x 4.1 x 2.5
Test data, Test instruments, and Test set up
Refer to APPENDIX.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
No. 5,6,8 SR
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 7 of 23
: April 19, 2018
: BKEHAC015
SECTION 4: Operation of E.U.T. during testing
4.1
Operating Mode(s)
Bluetooth (BT):
Transmitting (Tx), Payload: PRBS9
Details of Operating Mode(s)
Test Item
Spurious Emission
(Radiated)
Tested frequency
2402 MHz
2441 MHz
2480 MHz
*As a result of preliminary test, the formal test was performed with the above modes, which had the
maximum payload length (except Dwell time test)
*2DH mode (2Mb/s EDR: pi/4DQPSK) was excluded for other tests than power measurement by using
3DH mode (3 Mb/s EDR: 8DPSK) as a representative.
* It is considered that the non-tested packet type (e.g. inquiry) can be omitted as it is complied with above
all the test items based on Bluetooth Core specification.
Power settings:
Fixed
Software:
cmd.exe, Ver. 10.0.14393,
Bluetool.exe, Ver.1.9.6.5
*This setting of software is the worst case.
Any conditions under the normal use do not exceed the condition of setting.
In addition, end users cannot change the settings of the output power of the product.
4.2
Mode
Tx (Hopping Off) DH5, 3DH5
Configuration and peripherals
* Cabling and setup(s) were taken into consideration and test data was taken under worse case conditions.
Description of EUT and Support equipment
No. Item
Model number
Wireless Game Device
HAC-015
Serial number
XBW01000010563
Manufacturer
Nintendo Co., Ltd.
Accessory and model differences
There are Type-A and Type-B in HAC-015 and the difference is the manufacturer of parts.
The difference between Type-A and Type-B is as following table.
The two crystals and 1.8 V LDO are compatible and are electrically identical having same radio parameters.
Type-A
Type-B
Crystal (X1)
DSX211SH
7R24080002
1.8 V LDO (U32)
LD39020DTPU18R
RP202K181D
Because of only the change of antenna, the test was performed with Type-B as a representative.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Remark
EUT
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 8 of 23
: April 19, 2018
: BKEHAC015
SECTION 5: Radiated Spurious Emission
Test Procedure
[For below 1 GHz]
EUT was placed on a urethane platform of nominal size, 1.5 m by 1.0 m, raised 0.8 m above the conducting ground
plane. The Radiated Electric Field Strength has been measured in a Semi Anechoic Chamber with a ground plane.
[For above 1 GHz]
EUT was placed on a urethane platform of nominal size, 0.5 m by 0.5 m, raised 1.5 m above the conducting ground
plane.
The Radiated Electric Field Strength has been measured in a Semi Anechoic Chamber with absorbent materials lined
on a ground plane.
The height of the measuring antenna varied between 1 and 4 m and EUT was rotated a full revolution in order to
obtain the maximum value of the electric field strength.
The measurements were performed for both vertical and horizontal antenna polarization with the Test Receiver, or the
Spectrum Analyzer.
The measurements were made with the following detector function of the test receiver and the Spectrum analyzer (in
linear mode).
The test was made with the detector (RBW/VBW) in the following table.
When using Spectrum analyzer, the test was made with adjusting span to zero by using peak hold.
Test Antennas are used as below;
Frequency
30 MHz to 200 MHz
Antenna Type
Biconical
200 MHz to 1 GHz
Logperiodic
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Above 1 GHz
Horn
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 9 of 23
: April 19, 2018
: BKEHAC015
In any 100 kHz bandwidth outside the restricted band in which the spread spectrum intentional radiator is operating,
the radio frequency power that is produced by the intentional radiator confirmed 20 dB below that in the 100 kHz
bandwidth within the band that contains the highest level of the desired power, based on a radiated measurement.
20 dBc was applied to the frequency over the limit of FCC 15.209 / Table 4 of RSS-Gen 8.9 (IC) and outside the
restricted band of FCC15.205 / Table 6 of RSS-Gen 8.10 (IC).
Frequency
Below 1 GHz
Above 1 GHz
20 dBc
Instrument used
Test Receiver
Spectrum Analyzer
Spectrum Analyzer
Detector
QP
PK
AV
PK
IF Bandwidth
BW 120 kHz
RBW: 1 MHz
RBW: 1 MHz
RBW: 100 kHz
VBW: 3 MHz
VBW: 10 Hz *1)
VBW: 300 kHz
Test Distance
3m
3.95 m*2) (1 GHz – 10 GHz),
3.95 m*2) (1 GHz – 10 GHz),
1 m*3) (10 GHz – 26.5 GHz)
1 m*3) (10 GHz – 26.5 GHz)
*1) Although DA 00-705 accepts VBW = 10 Hz for AV measurements, it was confirmed that superfluous smoothing was
not performed.
*2) Distance Factor: 20 x log (3.95 m/3.0 m) = 2.39 dB
*3) Distance Factor: 20 x log (1.0 m/3.0 m) = -9.54 dB
- The carrier level and noise levels were confirmed at each position of X, Y and Z axes of EUT to see the position of
maximum noise, and the test was made at the position that has the maximum noise.
Antenna
Carrier
Spurious
Spurious
Spurious
polarization
(Below 1 GHz)
(2.8 GHz -13 GHz) (13 GHz -26.5 GHz)
Horizontal
Vertical
The test results and limit are rounded off to one decimal place, so some differences might be observed.
Measurement range
Test data
Test result
: 30 MHz - 26.5 GHz
: APPENDIX
: Pass
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 10 of 23
: April 19, 2018
: BKEHAC015
APPENDIX 1: Test data
Radiated Spurious Emission
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
No.3
March 15, 2018
March 19, 2018
24 deg. C / 37 % RH
24 deg. C / 38 % RH
Hiroyuki Morikawa
Kazutaka Takeyama
(30 MHz -1 GHz)
(1 GHz -13 GHz)
Tx, Hopping Off, DH5 2402 MHz
No.3
March 15, 2018
24 deg. C / 37 % RH
Hiroyuki Morikawa
(13 GHz -26.5 GHz)
(* P K: P eak, AV: Average, QP : Quasi-P eak)
Polarity
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Frequency
[MHz]
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1441.200
2390.000
3843.183
4794.056
4804.000
7206.000
9608.000
12010.000
1441.200
2390.000
3843.183
4794.056
4804.000
7206.000
9608.000
12010.000
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1441.200
2390.000
3843.183
4794.056
4804.000
7206.000
9608.000
12010.000
1441.200
2390.000
3843.183
4794.056
4804.000
7206.000
9608.000
12010.000
Detector
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
AV
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
AV
Reading
[dBuV]
22.10
22.60
22.10
22.60
21.90
22.10
21.80
47.84
47.70
49.60
47.90
48.40
47.00
46.40
45.50
36.30
36.80
41.20
38.30
38.30
36.80
37.80
37.00
22.20
22.80
22.30
22.60
21.90
22.30
21.90
47.10
47.00
50.10
49.40
48.20
46.70
48.10
47.90
36.30
38.30
42.70
38.50
39.00
36.90
37.80
37.30
Ant.Fac.
[dB/m]
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.94
27.26
29.45
31.38
31.40
36.56
38.61
39.30
24.94
27.26
29.45
31.38
31.40
36.56
38.61
39.30
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.94
27.26
29.45
31.38
31.40
36.56
38.61
39.30
24.94
27.26
29.45
31.38
31.40
36.56
38.61
39.30
Loss
[dB]
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.21
14.19
6.35
6.67
6.68
8.24
9.27
10.48
13.21
14.19
6.35
6.67
6.68
8.24
9.27
10.48
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.21
14.19
6.35
6.67
6.68
8.24
9.27
10.48
13.21
14.19
6.35
6.67
6.68
8.24
9.27
10.48
Gain
[dB]
Distance
Result
Factor [dB] [dBuV/m]
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.13
44.30
44.45
44.45
43.99
43.83
43.36
43.79
44.13
44.30
44.45
44.45
43.99
43.83
43.36
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.13
44.30
44.45
44.45
43.99
43.83
43.36
43.79
44.13
44.30
44.45
44.45
43.99
43.83
43.36
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
8.20
3.74
6.83
10.83
12.11
13.57
13.85
44.59
47.41
43.49
43.89
44.42
50.20
52.84
54.31
33.05
36.51
35.09
34.29
34.32
40.00
44.24
45.81
8.30
3.94
7.03
10.83
12.11
13.77
13.95
43.85
46.71
43.99
45.39
44.22
49.90
54.54
56.71
33.05
38.01
36.59
34.49
35.02
40.10
44.24
46.11
Limit
[dBuV/m]
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
Margin
[dB]
31.8
36.2
36.6
32.6
31.3
29.9
29.6
29.3
26.4
30.4
30.0
29.4
23.7
21.0
19.5
20.8
17.3
18.8
19.6
19.5
13.9
9.6
8.0
31.7
36.0
36.4
32.6
31.3
29.7
29.5
30.0
27.1
29.9
28.5
29.6
24.0
19.3
17.1
20.8
15.8
17.3
19.4
18.8
13.8
9.6
7.7
Height
[cm]
100
100
100
100
100
100
100
238
238
100
100
100
100
100
100
238
238
100
100
100
100
100
100
100
100
100
100
100
100
100
237
237
100
100
100
100
100
100
237
237
100
100
100
100
100
100
Result = Reading + Ant.Fac. + Loss (Cable+(Attenuator or Filter)(below 18 GHz)) - Gain(Amprifier) + Distance factor
Distance factor : 1 GHz - 13 GHz : 20log (3.95 m / 3.0 m) = 2.39 dB
13 GHz - 40 GHz : 20log (1.0 m / 3.0 m) = -9.54 dB
* These results have sufficient margin without taking account Dwell time factor.
20 dBc Data S heet
Polarity
Frequency
[MHz]
(RBW 100 kHz , VBW 300 kHz )
Detector
Reading
Ant.Fac.
[dBuV]
[dB/m]
Loss
[dB]
Gain
[dB]
Distance
Result
Factor [dB] [dBuV/m]
Limit
[dBuV/m]
Hori.
2402.000 PK
94.50
27.29
14.20
44.14
2.39
94.24
Hori.
2400.000 PK
39.40
27.29
14.19
44.14
2.39
39.13
74.24
Vert.
2402.000 PK
93.85
27.29
14.20
44.14
2.39
93.59
Vert.
2400.000 PK
39.30
27.29
14.19
44.14
2.39
39.03
73.59
Result = Reading + Ant.Fac. + Loss (Cable+(Attenuator or Filter)(below 18 GHz)) - Gain(Amprifier) + Distance factor
Distance factor : 1 GHz - 13 GHz : 20log (3.95 m / 3.0 m) = 2.39 dB
13 GHz - 40 GHz : 20log (1.0 m / 3.0 m) = -9.54 dB
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Margin
[dB]
Remark
- Carrier
35.1
- Carrier
34.6
Angle
[deg]
276
276
207
276
276
207
107
107
355
107
107
355
Remark
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 11 of 23
: April 19, 2018
: BKEHAC015
Radiated Spurious Emission
(Reference Plot for band-edge)
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
March 19, 2018
24 deg. C / 38 % RH
Kazutaka Takeyama
(1 GHz -13 GHz)
Tx, Hopping Off, DH5 2402 MHz
Horizontal
Restricted-band band-edge Plot
Authorized-band band-edge Plot
Trace Green : Peak Plot
Trace Purple : Average Plot
20dBc Plot
Vertical
Restricted-band band-edge Plot
Authorized-band band-edge Plot
Trace Green : Peak Plot
Trace Purple : Average Plot
* Final result of restricted band edge was shown in tabular data.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
20dBc Plot
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 12 of 23
: April 19, 2018
: BKEHAC015
Radiated Spurious Emission
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
No.3
March 15, 2018
March 19, 2018
24 deg. C / 37 % RH
24 deg. C / 38 % RH
Hiroyuki Morikawa
Kazutaka Takeyama
(30 MHz -1 GHz)
(1 GHz -13 GHz)
No.3
No.3
Tx, Hopping Off, DH5 2441 MHz
March 15, 2018
24 deg. C / 37 % RH
Hiroyuki Morikawa
(13 GHz -26.5 GHz)
No.3
(* P K: P eak, AV: Average, QP : Quasi-P eak)
Polarity
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Frequency
[MHz]
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1464.610
3905.591
4793.980
4882.000
7323.000
9764.000
12205.000
1464.610
3905.591
4793.980
4882.000
7323.000
9764.000
12205.000
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1464.610
3905.591
4793.980
4882.000
7323.000
9764.000
12205.000
1464.610
3905.591
4793.980
4882.000
7323.000
9764.000
12205.000
Detector
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
Reading
[dBuV]
22.10
22.60
22.10
22.60
21.90
22.10
21.80
49.80
49.60
48.80
48.30
46.40
46.40
47.60
38.00
41.60
38.30
38.10
37.30
37.20
37.30
22.10
22.70
22.30
22.60
21.80
22.30
21.90
49.50
51.50
50.00
49.20
48.66
49.40
48.70
37.90
44.20
38.60
38.60
37.20
37.60
37.30
Ant.Fac.
[dB/m]
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.96
29.57
31.38
31.62
36.77
38.80
39.28
24.96
29.57
31.38
31.62
36.77
38.80
39.28
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.96
29.57
31.38
31.62
36.77
38.80
39.28
24.96
29.57
31.38
31.62
36.77
38.80
39.28
Loss
[dB]
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.25
6.38
6.67
6.70
8.26
9.33
10.50
13.25
6.38
6.67
6.70
8.26
9.33
10.50
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.25
6.38
6.67
6.70
8.26
9.33
10.50
13.25
6.38
6.67
6.70
8.26
9.33
10.50
Gain
[dB]
Distance
Result
Factor [dB] [dBuV/m]
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.24
44.45
44.48
44.03
43.85
43.36
43.79
44.24
44.45
44.48
44.03
43.85
43.36
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.24
44.45
44.48
44.03
43.85
43.36
43.79
44.24
44.45
44.48
44.03
43.85
43.36
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
8.20
3.74
6.83
10.83
12.11
13.57
13.85
46.61
43.70
44.79
44.53
49.79
53.07
56.41
34.81
35.70
34.29
34.33
40.69
43.87
46.11
8.20
3.84
7.03
10.83
12.01
13.77
13.95
46.31
45.60
45.99
45.43
52.05
56.07
57.51
34.71
38.30
34.59
34.83
40.59
44.27
46.11
Limit
[dBuV/m]
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
Result = Reading + Ant.Fac. + Loss (Cable+(Attenuator or Filter)(below 18 GHz)) - Gain(Amprifier) + Distance factor
Distance factor : 1 GHz - 13 GHz : 20log (3.95 m / 3.0 m) = 2.39 dB
13 GHz - 40 GHz : 20log (1.0 m / 3.0 m) = -9.54 dB
* These results have sufficient margin without taking account Dwell time factor.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Margin
[dB]
31.8
36.2
36.6
32.6
31.3
29.9
29.6
27.2
30.2
29.1
29.3
24.1
20.8
17.4
19.0
18.2
19.6
19.5
13.2
10.0
7.7
31.8
36.1
36.4
32.6
31.4
29.7
29.5
27.5
28.3
27.9
28.4
21.8
17.8
16.3
19.1
15.6
19.3
19.0
13.3
9.6
7.7
Height
[cm]
100
100
100
100
100
100
100
100
200
100
100
100
100
100
100
200
100
100
100
100
100
100
100
100
100
100
100
100
100
142
103
100
100
100
100
100
142
103
100
100
100
100
Angle
[deg]
200
200
347
347
Remark
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 13 of 23
: April 19, 2018
: BKEHAC015
Radiated Spurious Emission
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
No.3
March 15, 2018
March 21, 2018
24 deg. C / 37 % RH
22 deg. C / 38 % RH
Hiroyuki Morikawa
Hiroyuki Morikawa
(30 MHz -1 GHz)
(1 GHz -13 GHz)
Tx, Hopping Off, DH5 2480 MHz
No.3
March 15, 2018
24 deg. C / 37 % RH
Hiroyuki Morikawa
(13 GHz -26.5 GHz)
(* P K: P eak, AV: Average, QP : Quasi-P eak)
Polarity
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Frequency
[MHz]
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1488.014
2483.500
3968.004
4793.969
4960.000
7440.000
9920.000
12400.000
1488.014
2483.500
3968.004
4793.969
4960.000
7440.000
9920.000
12400.000
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1488.007
2483.500
3968.015
4793.989
4960.000
7440.000
9920.000
12400.000
1488.007
2483.500
3968.015
4793.989
4960.000
7440.000
9920.000
12400.000
Detector
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
AV
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
AV
Reading
[dBuV]
22.20
22.60
22.10
22.60
21.90
22.10
21.90
49.02
49.90
50.87
51.34
50.57
49.79
49.85
48.90
37.27
37.10
42.42
38.76
38.65
38.11
37.91
37.40
22.20
22.80
22.30
22.60
21.90
22.30
21.90
48.89
49.35
51.20
50.95
50.24
49.33
49.14
48.12
37.08
37.18
43.86
38.41
38.76
37.85
37.72
37.37
Ant.Fac.
[dB/m]
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.99
27.55
29.68
31.38
31.83
36.97
38.98
39.26
24.99
27.55
29.68
31.38
31.83
36.97
38.98
39.26
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.99
27.55
29.68
31.38
31.83
36.97
38.98
39.26
24.99
27.55
29.68
31.38
31.83
36.97
38.98
39.26
Loss
[dB]
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.28
14.29
6.41
6.67
6.72
8.27
9.38
10.52
13.28
14.29
6.41
6.67
6.72
8.27
9.38
10.52
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.28
14.29
6.41
6.67
6.72
8.27
9.38
10.52
13.28
14.29
6.41
6.67
6.72
8.27
9.38
10.52
Gain
[dB]
Distance
Result
Factor [dB] [dBuV/m]
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.16
44.19
44.45
44.51
44.08
43.87
43.36
43.79
44.16
44.19
44.45
44.51
44.08
43.87
43.36
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.16
44.19
44.45
44.51
44.08
43.87
43.36
43.79
44.16
44.19
44.45
44.51
44.08
43.87
43.36
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
8.30
3.74
6.83
10.83
12.11
13.57
13.95
45.89
49.97
45.16
47.33
47.00
53.34
56.73
57.71
34.14
37.17
36.71
34.75
35.08
41.66
44.79
46.21
8.30
3.94
7.03
10.83
12.11
13.77
13.95
45.76
49.42
45.49
46.94
46.67
52.88
56.02
56.93
33.95
37.25
38.15
34.40
35.19
41.40
44.60
46.18
Limit
[dBuV/m]
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
Result = Reading + Ant.Fac. + Loss (Cable+(Attenuator or Filter)(below 18 GHz)) - Gain(Amprifier) + Distance factor
Distance factor : 1 GHz - 13 GHz : 20log (3.95 m / 3.0 m) = 2.39 dB
13 GHz - 40 GHz : 20log (1.0 m / 3.0 m) = -9.54 dB
* These results have sufficient margin without taking account Dwell time factor.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Margin
[dB]
31.7
36.2
36.6
32.6
31.3
29.9
29.5
28.0
23.9
28.7
26.5
26.9
20.5
17.1
16.1
19.7
16.7
17.1
19.1
18.8
12.2
9.1
7.6
31.7
36.0
36.4
32.6
31.3
29.7
29.5
28.1
24.4
28.4
26.9
27.2
21.0
17.8
16.9
19.9
16.6
15.7
19.5
18.7
12.5
9.3
7.7
Height
[cm]
100
100
100
100
100
100
100
100
244
182
205
100
100
100
100
100
244
182
205
100
100
100
100
100
100
100
100
100
100
100
100
238
168
152
100
100
100
100
100
238
168
152
100
100
100
100
Angle
[deg]
321
24
40
321
24
40
77
175
177
77
175
177
Remark
Test report No.
Page
Issued date
FCC ID
Radiated Spurious Emission
(Reference Plot for band-edge)
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
March 21, 2018
22 deg. C / 38 % RH
Hiroyuki Morikawa
(1 GHz -13 GHz)
Tx, Hopping Off, DH5 2480 MHz
Horizontal
Restricted-band band-edge Plot
Trace Green : Peak Plot
Trace Purple : Average Plot
Vertical
Restricted-band band-edge Plot
Trace Green : Peak Plot
Trace Purple : Average Plot
* Final result of restricted band edge was shown in tabular data.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
: 12208081S-C
: 14 of 23
: April 19, 2018
: BKEHAC015
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 15 of 23
: April 19, 2018
: BKEHAC015
Radiated Spurious Emission
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
No.3
March 15, 2018
March 21, 2018
24 deg. C / 37 % RH
22 deg. C / 38 % RH
Hiroyuki Morikawa
Hiroyuki Morikawa
(30 MHz -1 GHz)
(1 GHz -13 GHz)
Tx, Hopping Off, 3DH5 2402 MHz
No.3
March 15, 2018
24 deg. C / 37 % RH
Hiroyuki Morikawa
(13 GHz -26.5 GHz)
(* P K: P eak, AV: Average, QP : Quasi-P eak)
Polarity
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Frequency
[MHz]
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1441.208
2390.000
3843.182
4793.969
4804.000
7206.000
9608.000
12010.000
1441.208
2390.000
3843.182
4793.969
4804.000
7206.000
9608.000
12010.000
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1441.194
2390.000
3843.196
4794.096
4804.000
7206.000
9608.000
12010.000
1441.194
2390.000
3843.196
4794.096
4804.000
7206.000
9608.000
12010.000
Detector
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
AV
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
AV
Reading
[dBuV]
22.20
22.60
22.10
22.70
21.90
22.10
21.80
48.35
48.78
51.70
50.16
49.14
47.91
48.22
48.63
36.27
36.68
42.24
38.53
38.53
36.24
37.67
37.11
22.20
22.80
22.40
22.60
21.90
22.30
21.90
48.60
48.57
52.47
51.15
49.73
47.29
48.08
47.98
36.31
36.72
43.87
37.66
38.95
36.26
37.65
37.36
Ant.Fac.
[dB/m]
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.94
27.26
29.45
31.38
31.40
36.56
38.61
39.30
24.94
27.26
29.45
31.38
31.40
36.56
38.61
39.30
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.94
27.26
29.45
31.38
31.40
36.56
38.61
39.30
24.94
27.26
29.45
31.38
31.40
36.56
38.61
39.30
Loss
[dB]
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.21
14.19
6.35
6.67
6.68
8.24
9.27
10.48
13.21
14.19
6.35
6.67
6.68
8.24
9.27
10.48
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.21
14.19
6.35
6.67
6.68
8.24
9.27
10.48
13.21
14.19
6.35
6.67
6.68
8.24
9.27
10.48
Gain
[dB]
Distance
Result
Factor [dB] [dBuV/m]
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.13
44.30
44.45
44.45
43.99
43.83
43.36
43.79
44.13
44.30
44.45
44.45
43.99
43.83
43.36
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.13
44.30
44.45
44.45
43.99
43.83
43.36
43.79
44.13
44.30
44.45
44.45
43.99
43.83
43.36
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
8.30
3.74
6.83
10.93
12.11
13.57
13.85
45.10
48.49
45.59
46.15
45.16
51.11
54.66
57.44
33.02
36.39
36.13
34.52
34.55
39.44
44.11
45.92
8.30
3.94
7.13
10.83
12.11
13.77
13.95
45.35
48.28
46.36
47.14
45.75
50.49
54.52
56.79
33.06
36.43
37.76
33.65
34.97
39.46
44.09
46.17
Limit
[dBuV/m]
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
Margin
[dB]
31.7
36.2
36.6
32.5
31.3
29.9
29.6
28.8
25.4
28.3
27.7
28.7
22.7
19.2
16.4
20.8
17.5
17.7
19.3
19.3
14.4
9.7
7.9
31.7
36.0
36.3
32.6
31.3
29.7
29.5
28.5
25.6
27.5
26.7
28.1
23.4
19.3
17.1
20.8
17.4
16.1
20.2
18.9
14.4
9.8
7.7
Height
[cm]
100
100
100
100
100
100
100
100
214
155
168
100
100
100
100
100
214
155
168
100
100
100
100
100
100
100
100
100
100
100
100
152
153
148
100
100
100
100
100
152
153
148
100
100
100
100
Result = Reading + Ant.Fac. + Loss (Cable+(Attenuator or Filter)(below 18 GHz)) - Gain(Amprifier) + Distance factor
Distance factor : 1 GHz - 13 GHz : 20log (3.95 m / 3.0 m) = 2.39 dB
13 GHz - 40 GHz : 20log (1.0 m / 3.0 m) = -9.54 dB
* These results have sufficient margin without taking account Dwell time factor.
20 dBc Data S heet
Polarity
Frequency
[MHz]
(RBW 100 kHz , VBW 300 kHz)
Detector
Reading
Ant.Fac.
[dBuV]
[dB/m]
Loss
[dB]
Gain
[dB]
Distance
Result
Factor [dB] [dBuV/m]
Limit
[dBuV/m]
Hori.
2402.000 PK
94.76
27.29
14.20
44.14
2.39
94.50
Hori.
2400.000 PK
42.16
27.29
14.19
44.14
2.39
41.89
74.50
Vert.
2402.000 PK
93.36
27.29
14.20
44.14
2.39
93.10
Vert.
2400.000 PK
40.65
27.29
14.19
44.14
2.39
40.38
73.10
Result = Reading + Ant.Fac. + Loss (Cable+(Attenuator or Filter)(below 18 GHz)) - Gain(Amprifier) + Distance factor
Distance factor : 1 GHz - 13 GHz : 20log (3.95 m / 3.0 m) = 2.39 dB
13 GHz - 40 GHz : 20log (1.0 m / 3.0 m) = -9.54 dB
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Margin
[dB]
Remark
- Carrier
32.6
- Carrier
32.7
Angle
[deg]
122
33
47
122
33
47
112
191
176
112
191
176
Remark
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 16 of 23
: April 19, 2018
: BKEHAC015
Radiated Spurious Emission
(Reference Plot for band-edge)
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
March 21, 2018
22 deg. C / 38 % RH
Hiroyuki Morikawa
(1 GHz -13 GHz)
Tx, Hopping Off, 3DH5 2402 MHz
Horizontal
Restricted-band band-edge Plot
Authorized-band band-edge Plot
Trace Green : Peak Plot
Trace Purple : Average Plot
20dBc Plot
Vertical
Restricted-band band-edge Plot
Authorized-band band-edge Plot
Trace Green : Peak Plot
Trace Purple : Average Plot
* Final result of restricted band edge was shown in tabular data.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
20dBc Plot
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 17 of 23
: April 19, 2018
: BKEHAC015
Radiated Spurious Emission
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
No.3
March 15, 2018
March 21, 2018
24 deg. C / 37 % RH
22 deg. C / 38 % RH
Hiroyuki Morikawa
Hiroyuki Morikawa
(30 MHz -1 GHz)
(1 GHz -13 GHz)
Tx, Hopping Off, 3DH5 2441 MHz
No.3
March 15, 2018
24 deg. C / 37 % RH
Hiroyuki Morikawa
(13 GHz -26.5 GHz)
(* P K: P eak, AV: Average, QP : Quasi-P eak)
Polarity
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Frequency
[MHz]
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1464.596
3905.622
4793.917
4882.000
7323.000
9764.000
12205.000
1464.596
3905.622
4793.917
4882.000
7323.000
9764.000
12205.000
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1464.570
3905.646
4793.949
4882.000
7323.000
9764.000
12205.000
1464.570
3905.646
4793.949
4882.000
7323.000
9764.000
12205.000
Detector
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
Reading
[dBuV]
22.20
22.60
22.20
22.70
22.00
22.20
21.90
48.87
51.16
50.09
49.04
47.66
47.23
48.52
37.82
42.19
38.86
38.43
37.59
37.51
37.21
22.20
22.90
22.50
22.70
21.90
22.40
21.90
48.77
51.95
50.89
48.74
48.52
48.18
48.61
37.74
43.10
38.11
38.63
37.62
37.57
37.35
Ant.Fac.
[dB/m]
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.96
29.57
31.38
31.62
36.77
38.80
39.28
24.96
29.57
31.38
31.62
36.77
38.80
39.28
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.96
29.57
31.38
31.62
36.77
38.80
39.28
24.96
29.57
31.38
31.62
36.77
38.80
39.28
Loss
[dB]
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.25
6.38
6.67
6.70
8.26
9.33
10.50
13.25
6.38
6.67
6.70
8.26
9.33
10.50
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.25
6.38
6.67
6.70
8.26
9.33
10.50
13.25
6.38
6.67
6.70
8.26
9.33
10.50
Gain
[dB]
Distance
Result
Factor [dB] [dBuV/m]
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.24
44.45
44.48
44.03
43.85
43.36
43.79
44.24
44.45
44.48
44.03
43.85
43.36
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.24
44.45
44.48
44.03
43.85
43.36
43.79
44.24
44.45
44.48
44.03
43.85
43.36
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
8.30
3.74
6.93
10.93
12.21
13.67
13.95
45.68
45.26
46.08
45.27
51.05
53.90
57.33
34.63
36.29
34.85
34.66
40.98
44.18
46.02
8.30
4.04
7.23
10.93
12.11
13.87
13.95
45.58
46.05
46.88
44.97
51.91
54.85
57.42
34.55
37.20
34.10
34.86
41.01
44.24
46.16
Limit
[dBuV/m]
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
Result = Reading + Ant.Fac. + Loss (Cable+(Attenuator or Filter)(below 18 GHz)) - Gain(Amprifier) + Distance factor
Distance factor : 1 GHz - 13 GHz : 20log (3.95 m / 3.0 m) = 2.39 dB
13 GHz - 40 GHz : 20log (1.0 m / 3.0 m) = -9.54 dB
* These results have sufficient margin without taking account Dwell time factor.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Margin
[dB]
31.7
36.2
36.5
32.5
31.2
29.8
29.5
28.2
28.6
27.8
28.6
22.8
20.0
16.5
19.2
17.6
19.0
19.2
12.9
9.7
7.8
31.7
35.9
36.2
32.5
31.3
29.6
29.5
28.3
27.8
27.0
28.9
21.9
19.0
16.4
19.3
16.7
19.8
19.0
12.8
9.6
7.7
Height
[cm]
100
100
100
100
100
100
100
100
155
172
100
100
100
100
100
155
172
100
100
100
100
100
100
100
100
100
100
100
100
178
151
100
100
100
100
100
178
151
100
100
100
100
Angle
[deg]
36
49
36
49
171
173
171
173
Remark
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 18 of 23
: April 19, 2018
: BKEHAC015
Radiated Spurious Emission
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
No.3
March 15, 2018
March 21, 2018
24 deg. C / 37 % RH
22 deg. C / 38 % RH
Hiroyuki Morikawa
Hiroyuki Morikawa
(30 MHz -1 GHz)
(1 GHz -13 GHz)
Tx, Hopping Off, 3DH5 2480 MHz
No.3
March 15, 2018
24 deg. C / 37 % RH
Hiroyuki Morikawa
(13 GHz -26.5 GHz)
(* P K: P eak, AV: Average, QP : Quasi-P eak)
Polarity
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Hori.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Vert.
Frequency
[MHz]
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1488.019
2483.500
3968.082
4793.985
4960.000
7440.000
9920.000
12400.000
1488.019
2483.500
3968.082
4793.985
4960.000
7440.000
9920.000
12400.000
48.000
72.000
96.000
120.000
144.000
168.000
192.000
1488.021
2483.500
3968.041
4793.977
4960.000
7440.000
9920.000
12400.000
1488.021
2483.500
3968.041
4793.977
4960.000
7440.000
9920.000
12400.000
Detector
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
AV
QP
QP
QP
QP
QP
QP
QP
PK
PK
PK
PK
PK
PK
PK
PK
AV
AV
AV
AV
AV
AV
AV
AV
Reading
[dBuV]
22.20
22.70
22.20
22.70
21.90
22.30
21.90
48.81
49.47
51.24
50.67
49.85
49.90
48.98
48.53
37.92
37.26
42.27
38.81
38.70
38.09
37.90
37.38
22.20
22.90
22.40
22.70
21.90
22.30
21.90
48.29
49.11
51.45
50.09
50.11
49.58
48.93
47.86
37.91
37.04
42.73
38.84
38.80
37.98
37.84
37.38
Ant.Fac.
[dB/m]
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.99
27.55
29.68
31.38
31.83
36.97
38.98
39.26
24.99
27.55
29.68
31.38
31.83
36.97
38.98
39.26
11.35
6.21
9.29
12.97
14.50
15.54
16.16
24.99
27.55
29.68
31.38
31.83
36.97
38.98
39.26
24.99
27.55
29.68
31.38
31.83
36.97
38.98
39.26
Loss
[dB]
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.28
14.29
6.41
6.67
6.72
8.27
9.38
10.52
13.28
14.29
6.41
6.67
6.72
8.27
9.38
10.52
6.94
7.11
7.60
7.40
7.83
8.03
7.97
13.28
14.29
6.41
6.67
6.72
8.27
9.38
10.52
13.28
14.29
6.41
6.67
6.72
8.27
9.38
10.52
Gain
[dB]
Distance
Result
Factor [dB] [dBuV/m]
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.16
44.19
44.45
44.51
44.08
43.87
43.36
43.79
44.16
44.19
44.45
44.51
44.08
43.87
43.36
32.19
32.18
32.16
32.14
32.12
32.10
32.08
43.79
44.16
44.19
44.45
44.51
44.08
43.87
43.36
43.79
44.16
44.19
44.45
44.51
44.08
43.87
43.36
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
0.00
0.00
0.00
0.00
0.00
0.00
0.00
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
2.39
8.30
3.84
6.93
10.93
12.11
13.77
13.95
45.68
49.54
45.53
46.66
46.28
53.45
55.86
57.34
34.79
37.33
36.56
34.80
35.13
41.64
44.78
46.19
8.30
4.04
7.13
10.93
12.11
13.77
13.95
45.16
49.18
45.74
46.08
46.54
53.13
55.81
56.67
34.78
37.11
37.02
34.83
35.23
41.53
44.72
46.19
Limit
[dBuV/m]
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
40.00
40.00
43.50
43.50
43.50
43.50
43.50
73.90
73.90
73.90
73.90
73.90
73.90
73.90
73.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
53.90
Result = Reading + Ant.Fac. + Loss (Cable+(Attenuator or Filter)(below 18 GHz)) - Gain(Amprifier) + Distance factor
Distance factor : 1 GHz - 13 GHz : 20log (3.95 m / 3.0 m) = 2.39 dB
13 GHz - 40 GHz : 20log (1.0 m / 3.0 m) = -9.54 dB
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Margin
[dB]
31.7
36.1
36.5
32.5
31.3
29.7
29.5
28.2
24.3
28.3
27.2
27.6
20.4
18.0
16.5
19.1
16.5
17.3
19.1
18.7
12.2
9.1
7.7
31.7
35.9
36.3
32.5
31.3
29.7
29.5
28.7
24.7
28.1
27.8
27.3
20.7
18.0
17.2
19.1
16.7
16.8
19.0
18.6
12.3
9.1
7.7
Height
[cm]
100
100
100
100
100
100
100
100
237
158
191
100
100
100
100
100
237
158
191
100
100
100
100
100
100
100
100
100
100
100
100
264
149
152
100
100
100
100
100
264
149
152
100
100
100
100
Angle
[deg]
128
23
37
128
23
37
80
207
182
80
207
182
Remark
Test report No.
Page
Issued date
FCC ID
Radiated Spurious Emission
(Reference Plot for band-edge)
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
March 21, 2018
22 deg. C / 38 % RH
Hiroyuki Morikawa
(1 GHz -13 GHz)
Tx, Hopping Off, 3DH5 2480 MHz
Horizontal
Restricted-band band-edge Plot
Trace Green : Peak Plot
Trace Purple : Average Plot
Vertical
Restricted-band band-edge Plot
Trace Green : Peak Plot
Trace Purple : Average Plot
* Final result of restricted band edge was shown in tabular data.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
: 12208081S-C
: 19 of 23
: April 19, 2018
: BKEHAC015
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 20 of 23
: April 19, 2018
: BKEHAC015
Radiated Spurious Emission
(Plot data, Worst case)
Report No.
Test place
Semi Anechoic Chamber
Date
Temperature / Humidity
Engineer
Mode
12208081S-C
Shonan EMC Lab.
No.3
No.3
March 15, 2018
March 21, 2018
24 deg. C / 37 % RH
22 deg. C / 38 % RH
Hiroyuki Morikawa
Hiroyuki Morikawa
(30 MHz -1 GHz)
(1 GHz -13 GHz)
Tx, Hopping Off, DH5 2441 MHz
No.3
March 15, 2018
24 deg. C / 37 % RH
Hiroyuki Morikawa
(13 GHz -26.5 GHz)
*These plots data contains sufficient number to show the trend of characteristic features for EUT.
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Test report No.
Page
Issued date
FCC ID
: 12208081S-C
: 21 of 23
: April 19, 2018
: BKEHAC015
APPENDIX 2: Test instruments
Test Instruments
Control No.
SAEC-03(NSA)
Instrument
Semi-Anechoic
Manufacturer
Model No
TDK
SAEC-03(NSA)
Serial No
Test Item
Calibration Date *
Interval(month)
RE
2017/06/11 * 12
Chamber
SBA-03
Biconical Antenna
Schwarzbeck
BBA9106
91032666
RE
2017/10/02 * 12
SLA-07
Logperiodic
Schwarzbeck
VUSLP9111B
196
RE
2018/01/30 * 12
HIROSE ELECTRIC
AT-406(40)
RE
2017/08/24 * 12
RE
2017/04/07 * 12
Antenna
SAT6-08
Attenuator
CO.,LTD.
SCC-C1/C2/C3/C Coaxial Cable&RF
Fujikura/Fujikura/Suhne 8D2W/12DSFA/1 -/0901-271(RF
4/C5/C10/SRSE- Selector
r/Suhner/Suhner/Suhner/ 41PE/141PE/141P Selector)
03
TOYO
E/141PE/NS4906
SAF-03
Pre Amplifier
SONOMA
310N
290213
RE
2018/02/16 * 12
STR-08
Test Receiver
Rohde & Schwarz
ESW44
101581
RE
2017/11/24 * 12
COTS-SEMI-1
EMI Software
TSJ
TEPTO-DV(RE,C -
RE
E,RFI,MF)
SOS-05
Humidity Indicator
A&D
AD-5681
4062518
RE
2017/10/30 * 12
SJM-02
Measure
KOMELON
KMC-36
RE
STS-03
Digital Hitester
Hioki
3805-50
080997823
RE
2017/10/16 * 12
SSA-02
Spectrum Analyzer
Agilent
E4448A
MY48250106
RE
2018/03/05 * 12
SHA-05
Horn Antenna
ETS LINDGREN
3160-09
LM4210
RE
2017/03/15 * 12
SAF-09
Pre Amplifier
TOYO Corporation
HAP18-26W
00000018
RE
2017/09/22 * 12
SCC-G19
Coaxial Cable
Suhner
SUCOFLEX
1188/2A
RE
2017/03/23 * 12
SCC-G33
Coaxial Cable
Junkosha
RE
2017/04/20 * 12
102A
MWX241-01000
KMSKMS
SAF-06
Pre Amplifier
TOYO Corporation
TPA0118-36
2046104
RE
2017/09/22 * 12
SCC-G06
Coaxial Cable
Junkosha
J12J102207-00
MAY-23-16-091
RE
2017/06/13 * 12
SCC-G23
Coaxial Cable
Suhner
SUCOFLEX 104
297342/4
RE
2017/05/08 * 12
SHA-03
Horn Antenna
Schwarzbeck
BBHA9120D
9120D-739
RE
2017/08/23 * 12
SFL-02
Highpass Filter
MICRO-TRONICS
HPM50111
051
RE
2017/11/16 * 12
KSA-08
Spectrum Analyzer
Agilent
E4446A
MY46180525
TDK
SAEC-03(SVSW 3
SAEC-03(SVSW Semi-Anechoic
R)
Chamber
SCC-G40
Coaxial Cable
RE
2017/10/10 * 12
RE
2017/07/17 * 12
1612S005
RE
2018/01/29 * 12
R)
Junkosha
MWX221-01000
NFSNMS/B
SAF-06
Pre Amplifier
TOYO Corporation
TPA0118-36
2046104
RE
2017/09/22 * 12
SAT10-06
Attenuator
Agilent
8493C-010
74865
RE
2017/11/22 * 12
*Hyphens for Calibration Due Date and Cal Int (month) are instruments that Calibration is not required (e.g.
software), or instruments checked in advance before use.
The expiration date of the calibration is the end of the expired month.
All equipment is calibrated with valid calibrations. Each measurement data is traceable to the national or
international standards.
As for some calibrations performed after the tested dates, those test equipment have been controlled by means
of an unbroken chains of calibrations.
Test item:
RE: Radiated Emission test
UL Japan, Inc.
Shonan EMC Lab.
1-22-3 Megumigaoka, Hiratsuka-shi, Kanagawa-ken, 259-1220 JAPAN
Telephone : +81 463 50 6400
Facsimile : +81 463 50 6401
Download: HAC015 Wireless Game Device Test Report 12208081S-C_FCC15Cx Nintendo Co Ltd
Mirror Download [FCC.gov]HAC015 Wireless Game Device Test Report 12208081S-C_FCC15Cx Nintendo Co Ltd
Document ID3826891
Application IDEPn9z/6MjljZfrFFwvBVzA==
Document Description03 FCC Test Report_DSS
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize24.35kB (304404 bits)
Date Submitted2018-04-23 00:00:00
Date Available2018-04-23 00:00:00
Creation Date2018-04-19 14:02:21
Producing SoftwareAcrobat Distiller 10.1.2 (Windows)
Document Lastmod2018-04-20 16:25:50
Document Title12208081S-C_FCC15Cx
Document CreatorPScript5.dll Version 5.2.2
Document Author: 80961

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          : 80961
Create Date                     : 2018:04:19 14:02:21+09:00
Modify Date                     : 2018:04:20 16:25:50+09:00
Has XFA                         : No
XMP Toolkit                     : Adobe XMP Core 5.2-c001 63.139439, 2010/09/27-13:37:26
Producer                        : Acrobat Distiller 10.1.2 (Windows)
Creator Tool                    : PScript5.dll Version 5.2.2
Metadata Date                   : 2018:04:20 16:25:50+09:00
Format                          : application/pdf
Title                           : Microsoft Word - 12208081S-C_FCC15C.docx
Creator                         : 80961
Document ID                     : uuid:ba5566e0-508d-4de9-aa89-4582a02a2f80
Instance ID                     : uuid:9148496d-0475-45f1-9df0-cd2116762bc5
Page Count                      : 21
