Document Details
| FCC ID | BMTTTV500ES |
|---|---|
| Document ID | 45994 |
| Document Type | Schematics |
| Description | 5a |
| Applicant | EMCEE Broadcast Products |
| Equipment Class | TTV500ES |
| Product Code | TTV500ES |
| Application ID | Ro2tTnoD5CXFKu2bQArsPQ== |
| Application Purpose | Original Equipment |
| Application Date | 1999-09-30 |
| Frequency Range | 54-216 MHz |
| FRN | 0013678875 |
| Certified By | Robert G. Nash VP Director of Engineering |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 1999-07-06 |
| Available | 1999-09-30 |
| Created | 2001-06-09 |
| Modified | 2001-06-09 |
| Pages | 34 |
| File Type | Adobe Acrobat PDF |
| File Size | 1045544 |
| File SHA-256 | d366baf43efb9a587b8ccc2239b4f6736004c7f857b3ef87baba6c165c28badb |
| PDF Metadata Producer | Acrobat Distiller 4.0 for Windows |
| FCC.gov Sources | FCC.gov 45994 |
