FCC ID BRWSPMBT1000
Transmitter/Receiver Bluetooth Programming Module
by Horizon Hobby, LLC
Grantee Code: BRW Product Code: SPMBT1000
Latest application date: 2016-06-02
Device Images
FCC ID Device Details
| FCC ID | BRWSPMBT1000 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | BRW |
| Product Code | SPMBT1000 |
| Applicant Business | Horizon Hobby, LLC 🇺🇸 |
| Related Domains |  horizonhobby.com |
| Equipment Class | Transmitter/Receiver Bluetooth Programming Module |
| Test Firm | Centre of Testing service Co., Ltd |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-06-02 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-06-02 | PDF 1.6 MB |
| Internal Photos | Internal Photos | 2016-06-02 | PDF 178.9 KB |
| External Photos | External Photos | 2016-06-02 | PDF 125.1 KB |
| Label | ID Label/Location Info | 2016-06-02 | PDF 85.8 KB |
| Test Setup photos | Test Setup Photos | 2016-06-02 | PDF 305.7 KB |
| Test Report | Test Report | 2016-06-02 | PDF 402.1 KB |
| Authorization Letter | Cover Letter(s) | 2016-06-02 | PDF 37 KB |
| Confidentiality Request | Cover Letter(s) | 2016-06-02 | PDF 62.1 KB |
| Limited Modular Approval request | Cover Letter(s) | 2016-06-02 | PDF 69.5 KB |
| Block Diagram Metadata only | Block Diagram | PDF 194.7 KB | |
| Schematics Metadata only | Schematics | PDF 46.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 141.9 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 115.5 KB |
Application Information
| Application ID | p5DtfwqMIBUFZUhHbbGx0A== |
|---|---|
| Final Action Date | 2016-06-02 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0006301931 |
| Model | SPMBT1000 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | Transmitter/Receiver Bluetooth Programming Module |
| Responsible Party | Jason Rosa, Lead Quality and Compliance Associate, compliance@horizonhobby.com , 217-403-3218 |
| Technical Contact | Susan, CENTRE OF TESTING SERVICE CO., LTD, ctszjy@cts-lab.com  , 86-20-22138571 |
| Test Firm | Vincent Yao, Centre of Testing service Co., Ltd, vincent.yao@cts-lab.com.cn  , 86-20-22138530 |
| TCB Email | certification@micomlabs.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| p5DtfwqMIBUFZUhHbbGx0A== | 2016-06-02 | Original Equipment |
Grants
TCB Grant - Application p5DtfwqMIBUFZUhHbbGx0A==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
MiCOM Labs 575 Boulder Court Pleasanton, CA 94566 |
Date of Grant: 06/02/2016 Application Dated: 06/02/2016 |
| Horizon Hobby, LLC |
| 2904 Research Rd. |
| Champaign, IL 61822 |
| Attention: Jason Rosa , Lead Quality and Compliance Associate |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | BRWSPMBT1000 |
| Name of Grantee: | Horizon Hobby, LLC |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Transmitter/Receiver Bluetooth Programming Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 20 | 15C | 2402.0 - 2480.0 |
| 20: | All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed. |
EAS Grant - Application p5DtfwqMIBUFZUhHbbGx0A==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Horizon Hobby, LLC 2904 Research Rd. Champaign, IL 61822 United States |
Date of Grant: 06/02/2016 Application Dated: 06/02/2016 |
| Attention: Jason Rosa , Lead Quality and Compliance Associate |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | BRWSPMBT1000 |
| Name of Grantee: | Horizon Hobby, LLC |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | Transmitter/Receiver Bluetooth Programming Module |
| Modular Type: | Limited Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 20 | 15C | 2402.0 - 2480.0 |
| 20: | All electrical and mechanical devices employed for spurious radiation suppression, including any modifications made during certification testing, must be incorporated in each unit marketed. |
| Mail To: |
