STX3 Transmitter Label Diagram - FCC ID BRWSTX3
FCC ID BRWSTX3
Label
Transmitter
Document preview loads when visible.
Document Details
| FCC ID | BRWSTX3 |
|---|---|
| Document ID | 4205681 |
| Document Type | ID Label/Location Info |
| Description | Label |
| Document Title | STX3_Label sample and Label Location更新 |
| Applicant | Horizon Hobby, LLC |
| Equipment Class | Transmitter |
| Product Code | STX3 |
| Application ID | 5SoaRrsoTcDRybmx4PjswQ== |
| Application Purpose | Original Equipment |
| Application Date | 2019-03-29 |
| Frequency Range | 2405-2475 MHz |
| FRN | 0006301931 |
| Test Firm | WALTEK TESTING GROUP CO., LTD. |
| Certified By | philo zhong General Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2019-03-18 |
| Available | 2019-03-29 |
| Created | 2019-03-14 |
| Modified | 2019-03-14 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 268095 |
| File SHA-256 | 435b19d0e714e2bf8c8c97e32cda51e7a45a0a009d0640f7382f8d015ca9b385 |
| PDF Metadata Author | Administrator |
| PDF Metadata Producer | Acrobat Elements 7.0.5 (Windows) Administrator |
| FCC.gov Sources | FCC.gov 4205681 |
