HX4B Teardown Internal Photos - FCC ID BSYHX4B
FCC ID BSYHX4B
Internal Photo
HX4B
Document Details
| FCC ID | BSYHX4B |
|---|---|
| Document ID | 28867 |
| Document Type | Internal Photos |
| Description | Internal Photo |
| Applicant | GMT Industrial Ltd |
| Equipment Class | HX4B |
| Product Code | HX4B |
| Application ID | /c1+LwSjGaEeyFv/xvj/Nw== |
| Application Purpose | Original Equipment |
| Application Date | 1999-10-05 |
| Frequency Range | 315 MHz |
| FRN | 0008764896 |
| Test Firm | Intertek Testing Services Hong Kong |
| Certified By | C.K.Lam Technical Manger |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 1999-03-25 |
| Available | 1999-10-05 |
| Pages | 0 |
| File Type | JPEG Image |
| File Size | 650514 |
| File SHA-256 | da88ae9bf9838ca924f4393133c5a163f3f6b9751da1e5f4e5e190a8a7a8fc28 |
| FCC.gov Sources | FCC.gov 28867, FCC.gov 28868 |
