TTS250MVX 250 Watt VHF Translator Test Report - FCC ID BZ5TTS250MVX
FCC ID BZ5TTS250MVX
video waveforms
250 Watt VHF Translator
by Larcan Inc
Document preview loads when visible.
Document Details
| FCC ID | BZ5TTS250MVX |
|---|---|
| Document ID | 451880 |
| Document Type | Test Report |
| Description | video waveforms |
| Applicant | Larcan Inc |
| Equipment Class | 250 Watt VHF Translator |
| Product Code | TTS250MVX |
| Application ID | 0FOZfNjKnimIbJMUE1vf4w== |
| Application Purpose | Original Equipment |
| Application Date | 2004-09-15 |
| Frequency Range | 54-216 MHz |
| FRN | 0006657324 |
| Certified By | John E. Tremblay V.P. Engineering |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2004-07-21 |
| Available | 2004-09-15 |
| Created | 2003-06-23 |
| Modified | 2003-06-23 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 757442 |
| File SHA-256 | c9bb10a4830633b127e334c0b27495cf570bf4e8a6624d1933e5ddd7b215cba8 |
| PDF Metadata Author | gRegistration->fName |
| PDF Metadata Producer | Adobe PhotoDeluxe Adobe PhotoDeluxe 2.0 for Windows |
| FCC.gov Sources | FCC.gov 451880 |
