LSBB2 Left Shifter with AIREA and BLE Radios... - FCC ID C9O-LSBB2

FCC ID C9O-LSBB2

External Photos (LS)

Left Shifter with AIREA and BLE Radios

by SRAM LLC.

Document preview loads when visible.

Document Details

FCC IDC9O-LSBB2
Document ID5078904
Document TypeExternal Photos
DescriptionExternal Photos (LS)
ApplicantSRAM LLC.
Equipment ClassLeft Shifter with AIREA and BLE Radios
Product CodeLSBB2
Application ID9xwAXUKdOS78QNeMasZoYQ==
Application PurposeOriginal Equipment
Application Date2021-01-31
Frequency Range2402-2480 MHz
FRN0021443403
Test FirmUL Verification Services Inc.
Certified ByLeo Yermakov
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/30/2021
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2021-01-14
Available2021-07-30
Created2020-09-17
Modified2020-09-17
Pages7
File TypeAdobe Acrobat PDF
File Size657263
File SHA-256f9cfe174cf3c0017de94d2c35e2a55baf8debb0d20d59bfce8f381a13c22a6e7
PDF Metadata ProducerAdobe Acrobat 20.12 Adobe Acrobat 20.12 Image Conversion Plug-in
FCC.gov SourcesFCC.gov 5078904
