W204HL3 Universal Garage Door Opener Test... - FCC ID CB2W204HL3
FCC ID CB2W204HL3
Test Setup DUT Side
Universal Garage Door Opener
Document Details
| FCC ID | CB2W204HL3 |
|---|---|
| Document ID | 619400 |
| Document Type | Test Setup Photos |
| Description | Test Setup DUT Side |
| Applicant | Johnson Controls Interiors L.L.C. |
| Equipment Class | Universal Garage Door Opener |
| Product Code | W204HL3 |
| Application ID | QO/u9pf46Ruhg0zHFl32Jg== |
| Application Purpose | Original Equipment |
| Application Date | 2006-02-23 |
| Frequency Range | 288-303.5 MHz |
| FRN | 0005935259 |
| Test Firm | Johnson Controls Interiors LLC |
| Certified By | Jeremy P. Bos Lead Engineer (RF/EMC) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2006-01-13 |
| Available | 2006-02-23 |
| Pages | 0 |
| File Type | JPEG Image |
| File Size | 154655 |
| File SHA-256 | b263fbf6b16faf5ae10f2e1a8d30f1bbcde8901ccbf93c3e735e6c7b512cf54f |
| FCC.gov Sources | FCC.gov 619400 |
