PC0132 Digital Keypad Teardown Internal Photos - FCC ID CCKPC0132

FCC ID CCKPC0132

Internal photos

Digital Keypad

by Digital Monitoring Products Inc

Document preview loads when visible.

Document Details

FCC IDCCKPC0132
Document ID2347122
Document TypeInternal Photos
DescriptionInternal photos
ApplicantDigital Monitoring Products Inc
Equipment ClassDigital Keypad
Product CodePC0132
Application IDT2YyzYW5C/Vwxu/SLoBSBg==
Application PurposeOriginal Equipment
Application Date2014-08-05
Frequency Range903.3-927.1 MHz
FRN0009869348
Test FirmTimco Engineering, Inc.
Certified ByTerry Shelton Director of Technical Design
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2014-08-05
Available2014-08-05
Created2014-07-30
Modified2014-07-30
Pages2
File TypeAdobe Acrobat PDF
File Size949481
File SHA-256d54a062f98a90fdfa508d6d2b0c0cbf54272d802f181f8c615279bd38c1d6dec
PDF Metadata AuthorSharon Hoffman Timco Engineering Inc
PDF Metadata ProducerSharon Hoffman Adobe PDF Library 10.0
FCC.gov SourcesFCC.gov 2347122
