PC0194 Wireless Smoke Ring Test Setup Photos - FCC ID CCKPC0194

FCC ID CCKPC0194

Test Photos

Wireless Smoke Ring

by Digital Monitoring Products Inc

Document preview loads when visible.

Document Details

FCC IDCCKPC0194
Document ID3639199
Document TypeTest Setup Photos
DescriptionTest Photos
ApplicantDigital Monitoring Products Inc
Equipment ClassWireless Smoke Ring
Product CodePC0194
Application IDd8ducPZBczaK/VQ70Xm9dQ==
Application PurposeOriginal Equipment
Application Date2017-11-16
Frequency Range905.6-924.4 MHz
FRN0009869348
Test FirmNebraska Center for Excellence in Electronics
Certified ByNic Johnson Technical Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2017-11-15
Available2017-11-16
Created2017-10-12
Modified2017-10-12
Pages3
File TypeAdobe Acrobat PDF
File Size582292
File SHA-25681692daed306f0bf975a6ab2de74fbfa05e281d34dd8aaf787b2185eef89016f
PDF Metadata AuthorNic Johnson
PDF Metadata ProducerMicrosoft® Word 2010 Microsoft® Word 2010
FCC.gov SourcesFCC.gov 3639199
