AR300 Audio Wireless System (Receiver) Schematics - FCC ID CCRAR300

FCC ID CCRAR300

Circuit Diagram

Audio Wireless System (Receiver)

by Sam Ash Music Corporation

Document preview loads when visible.

Document Details

FCC IDCCRAR300
Document ID1160672
Document TypeSchematics
DescriptionCircuit Diagram
Document TitleAR300-1&2 V1
ApplicantSam Ash Music Corporation
Equipment ClassAudio Wireless System (Receiver)
Product CodeAR300
Application ID+M/WojZoClpxvoRm0FD2Yw==
Application PurposeOriginal Equipment
Application Date2009-08-28
Frequency Range639.025-647 MHz
FRN0009055401
Test FirmIntertek Testing Services Hong Kong Ltd.
Certified ByBen Ho Senior Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2009-08-28
Available2009-08-28
Created2008-11-04
Modified2009-08-18
Pages2
File TypeAdobe Acrobat PDF
File Size288689
File SHA-2565c3869a37e2d88ad94e29d17e0865f9e5b3e026ff4a6adfdc82726cb956210ef
PDF Metadata AuthorRD16
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 1160672
