8DL5820 Door Window Security Transmitter... - FCC ID CFS8DL5820

FCC ID CFS8DL5820

Test Report Part 1

Door Window Security Transmitter

by Honeywell International Inc.

Document preview loads when visible.

Document Details

FCC IDCFS8DL5820
Document ID1093670
Document TypeTest Report
DescriptionTest Report Part 1
Document TitleEXHIBIT 5-1
ApplicantHoneywell International Inc.
Equipment ClassDoor Window Security Transmitter
Product Code8DL5820
Application IDeeUMgJwYZ1Yn4S/fSguvBQ==
Application PurposeClass II Permissive Change
Application Date2009-04-09
Frequency Range345 MHz
FRN0004071130
Test FirmHoneywell International Inc.
Certified ByKenneth Eskildsen Engineering Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2009-04-08
Available2009-04-09
Created2005-04-13
Modified2008-11-25
Pages1
File TypeAdobe Acrobat PDF
File Size34434
File SHA-256dbc9555f54fe862d3e90a4ae7cdaef2df400d378e47c61ab968f5db1eb569d4d
PDF Metadata AuthorE650365
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 6.0 (Windows)
FCC.gov SourcesFCC.gov 1093670
