8BUSD2500C 25 Watt Digital Transmitter... - FCC ID CHP8BUSD2500C
FCC ID CHP8BUSD2500C
TEST REPORT
25 Watt Digital Transmitter System
Document preview loads when visible.
Document Details
| FCC ID | CHP8BUSD2500C |
|---|---|
| Document ID | 84720 |
| Document Type | Test Report |
| Description | TEST REPORT |
| Applicant | Thomson Broadcast & Multimedia, Inc. |
| Equipment Class | 25 Watt Digital Transmitter System |
| Product Code | 8BUSD2500C |
| Application ID | 3uZRwA+yQxQ/BpmN+KyhwA== |
| Application Purpose | Original Equipment |
| Application Date | 2000-03-14 |
| Frequency Range | 2000-2700 MHz |
| FRN | 0012615910 |
| Certified By | Paulo R. Correa Director of Engineering |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2000-02-02 |
| Available | 2000-03-14 |
| Created | 2001-04-12 |
| Modified | 2001-04-12 |
| Pages | 14 |
| File Type | Microsoft Word |
| File Size | 637448 |
| File SHA-256 | ec2178c6c7dc24ec719bc5909eaba885f6669fa377ff7a182e4989c2df82a419 |
| PDF Metadata Producer | Acrobat Distiller 4.0 for Windows |
| FCC.gov Sources | FCC.gov 84720 |
