FCC ID CKENTG420
Solid State Transmitter-Receiver
by Japan Radio Co., Ltd.
Grantee Code: CKE Product Code: NTG420
Latest application date: 2016-08-18
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 9410 MHz | Original Equipment | 2016-08-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Usera manual(Installation) | Users Manual | 2016-08-26 | PDF 1.6 MB |
| Users manual(Operation) | Users Manual | 2016-08-26 | PDF 2.4 MB |
| Internal photos | Internal Photos | 2016-08-26 | PDF 4 MB |
| External photos | External Photos | 2016-08-26 | PDF 438.6 KB |
| ID lable & location | ID Label/Location Info | 2016-08-18 | PDF 37.4 KB |
| Test setup photos(Part 80) | Test Setup Photos | 2016-08-26 | PDF 833.2 KB |
| Test setup photos(Part 90) | Test Setup Photos | 2016-08-26 | PDF 837 KB |
| Test report1(Part 80) | Test Report | 2016-08-18 | PDF 3.6 MB |
| Test report1(Part 90) | Test Report | 2016-08-18 | PDF 3.6 MB |
| Test report2(Part 80) | Test Report | 2016-08-18 | PDF 502.8 KB |
| Test report2(Part 90) | Test Report | 2016-08-18 | PDF 498.9 KB |
| Authorization letter | Cover Letter(s) | 2016-08-18 | PDF 309.6 KB |
| Confidentiality letter(long) | Cover Letter(s) | 2016-08-18 | PDF 273.5 KB |
| Confidentiality letter(short) | Cover Letter(s) | 2016-08-18 | PDF 271.2 KB |
| Power of attorney | Cover Letter(s) | 2016-08-18 | PDF 81 KB |
| RF EX | RF Exposure Info | 2016-08-18 | PDF 12.1 KB |
| Block diagram Metadata only | Block Diagram | PDF 84.7 KB | |
| Schematics Metadata only | Schematics | PDF 1.8 MB | |
| Operational description(Antenna) Metadata only | Operational Description | PDF 119 KB | |
| Operational description(Spec) Metadata only | Operational Description | PDF 79.6 KB | |
| Parts list Metadata only | Parts List/Tune Up Info | PDF 358.7 KB | |
| Tune up info Metadata only | Parts List/Tune Up Info | PDF 559.3 KB |
Application Information
| Application ID | b9+RGwxOL5xaWfLaqQQ9QA== |
|---|---|
| Final Action Date | 2016-08-18 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0028126522 |
| Model | NTG420 |
| Frequency Range | 9410 MHz |
| Equipment Class | MRD - Marine Radar |
| Device Description | Solid State Transmitter-Receiver |
| Responsible Party | Yuji Kinoshita, General Manager, kinoshita.yuji@jrc.co.jp  , 1-408-217-9832 |
| Agent | Yoshihisa Yoshihisa Yoshihisa, UL Japan, Inc., Yoshihisa.Maeda@ul.com  , 81-596-24-8999 |
| Technical Contact | Akio Hayashi, UL Japan, Inc., Akio.Hayashi@ul.com , 81-463-50-6400 |
| Test Firm | Tetsuya Hashimoto, UL Japan, Inc. Shonan EMC EMC Lab., Tetsuya.Hashimoto@jp.ul.com  , +81-596-24-8116 |
| TCB Email | LST.FRE.CertNotice@ul.com |
| TCB Scope | B3: Maritime & Aviation Radio Services equipment in 47 CFR parts 80 & 87 |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 08/26/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is Conducted(Peak). The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures and limited as shown in this filing. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| b9+RGwxOL5xaWfLaqQQ9QA== | 2016-08-18 | Original Equipment |
Equipment Authorization
Grants
TCB Grant - Application b9+RGwxOL5xaWfLaqQQ9QA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 08/18/2016 Application Dated: 08/18/2016 |
| Japan Radio Co., Ltd. |
| 3000 Scott Blvd, |
| Suite 212, |
| Santa Clara,, CA 95054 |
| Attention: Yuji Kinoshita , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | CKENTG420 |
| Name of Grantee: | Japan Radio Co., Ltd. |
| Equipment Class: | Marine Radar |
| Notes: | Solid State Transmitter-Receiver |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 80, 90 | 9410.0 - 9410.0 | 211.0 | 1250.0 PM | 37M2P0N | |
| 80, 90 | 9440.0 - 9440.0 | 192.0 | 1250.0 PM | 14M2Q0N | |
| 80, 90 | 9410.0 - 9440.0 | 197.0 | 1250.0 PM | 43M5V0N |
| Output power listed is Conducted(Peak). The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures and limited as shown in this filing. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. |
EAS Grant - Application b9+RGwxOL5xaWfLaqQQ9QA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Japan Radio Co., Ltd. 3000 Scott Blvd, Suite 212, Santa Clara,, CA 95054 United States |
Date of Grant: 08/18/2016 Application Dated: 08/18/2016 |
| Attention: Yuji Kinoshita , General Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | CKENTG420 |
| Name of Grantee: | Japan Radio Co., Ltd. |
| Equipment Class: | Marine Radar |
| Notes: | Solid State Transmitter-Receiver |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 80, 90 | 9410.0 - 9410.0 | 211.0 | 1250.0 PM | 37M2P0N | |
| 80, 90 | 9440.0 - 9440.0 | 192.0 | 1250.0 PM | 14M2Q0N | |
| 80, 90 | 9410.0 - 9440.0 | 197.0 | 1250.0 PM | 43M5V0N |
| Output power listed is Conducted(Peak). The antenna(s) used for this transmitter must be fixed-mounted on outdoor permanent structures and limited as shown in this filing. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. |
