T32 AUDITORY ASSISTANCE DEVICE Block Diagram - FCC ID CNMT32

FCC ID CNMT32

BLOCK DIAGRAM

AUDITORY ASSISTANCE DEVICE

by Williams Sound, LLC

Document preview loads when visible.

Document Details

FCC IDCNMT32
Document ID722757
Document TypeBlock Diagram
DescriptionBLOCK DIAGRAM
ApplicantWilliams Sound, LLC
Equipment ClassAUDITORY ASSISTANCE DEVICE
Product CodeT32
Application IDWgGYyiPUBO7tmCXEE9kCEA==
Application PurposeOriginal Equipment
Application Date2006-10-31
Frequency Range72.1-72.9 MHz
FRN0008029316
Test FirmTimco Engineering, Inc.
Certified ByTOM LAKE
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-10-31
Available2006-10-31
Created2006-10-02
Modified2006-10-02
Pages1
File TypeAdobe Acrobat PDF
File Size38891
File SHA-25665a3f52db6843dfa7770b54516e4499ce154fa3c6b00a9c19e910ce831f40003
FCC.gov SourcesFCC.gov 722757
