RP7450H Remote Control Toy Receiver Block... - FCC ID CVTRP7450H

FCC ID CVTRP7450H

Block Diagram

Remote Control Toy Receiver

by Nikko Co Ltd

Document preview loads when visible.

Document Details

FCC IDCVTRP7450H
Document ID347849
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Title.橡.output
ApplicantNikko Co Ltd
Equipment ClassRemote Control Toy Receiver
Product CodeRP7450H
Application ID6qMG2GTC8lsAHgkVKLVgvg==
Application PurposeOriginal Equipment
Application Date2003-08-13
Frequency Range49.83-49.89 MHz
FRN0006995088
Test FirmJapan Quality Assurance Org.
Certified ByYoichi Maeda Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartYes
Submitted2003-08-13
Available2003-08-13
Created2003-06-11
Modified2003-06-11
Pages1
File TypeAdobe Acrobat PDF
File Size6631
File SHA-256cdb041f20f785771e62be47e1b1c482bea0435a2ac3bfdaa039f8d24f9ae3c30
PDF Metadata Author.橡.Maeda
PDF Metadata Producer.橡.CAM output Acrobat PDFWriter 4.0 Windows
FCC.gov SourcesFCC.gov 347849
