TP7820H Remote Control Toy Transmitter... - FCC ID CVTTP7820H
FCC ID CVTTP7820H
Schematic Diagram
Remote Control Toy Transmitter
by Nikko Co Ltd
Document preview loads when visible.
Document Details
| FCC ID | CVTTP7820H |
|---|---|
| Document ID | 381770 |
| Document Type | Schematics |
| Description | Schematic Diagram |
| Document Title | .橡.output |
| Applicant | Nikko Co Ltd |
| Equipment Class | Remote Control Toy Transmitter |
| Product Code | TP7820H |
| Application ID | Mc9ARi5IXIGHAY45p158KQ== |
| Application Purpose | Original Equipment |
| Application Date | 2003-12-16 |
| Frequency Range | 49.86 MHz |
| FRN | 0006995088 |
| Test Firm | Japan Quality Assurance Org. |
| Certified By | Yoichi Maeda |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-12-16 |
| Available | 2003-12-16 |
| Created | 2003-11-04 |
| Modified | 2003-11-04 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 14526 |
| File SHA-256 | 801bde8dfc2ebf27c2b837d2d4fe2c67493d00d7279d83fd4cfe757368582e72 |
| PDF Metadata Author | .橡.Maeda |
| PDF Metadata Producer | .橡.CAM output Acrobat PDFWriter 4.0 Windows |
| FCC.gov Sources | FCC.gov 381770 |
