WD1J0004 TPMS TUNER CONT External Photos - FCC ID CWTWD1J0004
FCC ID CWTWD1J0004
04 External Photo
TPMS TUNER CONT
Document preview loads when visible.
Document Details
| FCC ID | CWTWD1J0004 |
|---|---|
| Document ID | 3547526 |
| Document Type | External Photos |
| Description | 04 External Photo |
| Document Title | 04 External Photo.xls |
| Applicant | ALPS ALPINE CO., LTD. |
| Equipment Class | TPMS TUNER CONT |
| Product Code | WD1J0004 |
| Application ID | cW4JT4wVwWptXcmD9t3Buw== |
| Application Purpose | Original Equipment |
| Application Date | 2017-09-07 |
| Frequency Range | 314.975 MHz |
| FRN | 0006935803 |
| Test Firm | UL Japan, Inc. |
| Certified By | Yoshihisa Maeda Project Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2017-09-07 |
| Available | 2017-09-07 |
| Created | 2017-08-30 |
| Modified | 2017-08-30 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 118533 |
| File SHA-256 | a75dfe5d53ca887f355f37b8d4b4698e0eef50c61418b71734ea0119eead45c1 |
| PDF Metadata Author | 40767 |
| PDF Metadata Producer | Acrobat Distiller 10.1.2 (Windows) 40767 |
| FCC.gov Sources | FCC.gov 3547526 |
