WDU633 Vehicle Entry System Receiver Test... - FCC ID CWTWDU633
FCC ID CWTWDU633
Test Setup Photos
Vehicle Entry System Receiver
Document preview loads when visible.
Document Details
| FCC ID | CWTWDU633 |
|---|---|
| Document ID | 664183 |
| Document Type | Test Setup Photos |
| Description | Test Setup Photos |
| Document Title | 26IE0397_FCC |
| Applicant | ALPS ALPINE CO., LTD. |
| Equipment Class | Vehicle Entry System Receiver |
| Product Code | WDU633 |
| Application ID | Fs5Ga1j36ESqPwCU4w1MkQ== |
| Application Purpose | Original Equipment |
| Application Date | 2006-06-02 |
| Frequency Range | 315 MHz |
| FRN | 0006935803 |
| Test Firm | UL Japan, Inc. Yokowa EMC Lab. |
| Certified By | Hisayuki Kioka Team Leader of Application Group |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2006-06-02 |
| Available | 2006-06-02 |
| Created | 2006-05-22 |
| Modified | 2006-05-22 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 829442 |
| File SHA-256 | 141ab185afe36f0c005eee2dac5ae28cd5c34c08cb13997f76fb09c430db7e96 |
| PDF Metadata Author | 40782 |
| PDF Metadata Producer | Acrobat Distiller 5.0.5 (Windows) 40782 |
| FCC.gov Sources | FCC.gov 664183, FCC.gov 664168 |
