IFBT419A Wireless Microphone Transmitter... - FCC ID DBZIFBT419A

FCC ID DBZIFBT419A

Int Photos

Wireless Microphone Transmitter

by Lectrosonics Inc

Document preview loads when visible.

Document Details

FCC IDDBZIFBT419A
Document ID4066276
Document TypeInternal Photos
DescriptionInt Photos
Document TitleInternal Photos
ApplicantLectrosonics Inc
Equipment ClassWireless Microphone Transmitter
Product CodeIFBT419A
Application IDLpg0ZGMEvS5tay+8jpZu5Q==
Application PurposeOriginal Equipment
Application Date2018-11-09
Frequency Range486.4-511.9 MHz
FRN0007067481
Test FirmBay Area Compliance Laboratories Corporation
Certified ByRobert Cunnings
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date05/07/2019
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2018-11-09
Available2019-05-07
Created2018-11-09
Modified2018-11-09
Pages2
File TypeAdobe Acrobat PDF
File Size1216152
File SHA-256e393e7d7cdef93d683639ad2422cbf4b5d37206802c9dfd73ed15e1bf961ea07
PDF Metadata Authorrachel
PDF Metadata Producerrachel Acrobat Distiller 11.0 (Windows)
