SMDWBA1A Wireless Microphone Transmitter... - FCC ID DBZSMDWBA1A
FCC ID DBZSMDWBA1A
Int Photos
Wireless Microphone Transmitter
Document preview loads when visible.
Document Details
| FCC ID | DBZSMDWBA1A |
|---|---|
| Document ID | 4037404 |
| Document Type | Internal Photos |
| Description | Int Photos |
| Document Title | Internal Photos |
| Applicant | Lectrosonics Inc |
| Equipment Class | Wireless Microphone Transmitter |
| Product Code | SMDWBA1A |
| Application ID | nsrfuU1OGQfCLlnBooWEaQ== |
| Application Purpose | Original Equipment |
| Application Date | 2018-10-16 |
| Frequency Range | 470.1-537.575 MHz |
| FRN | 0007067481 |
| Test Firm | Bay Area Compliance Laboratories Corporation |
| Certified By | Robert Cunnings |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 04/14/2019 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2018-10-16 |
| Available | 2019-04-14 |
| Created | 2018-10-16 |
| Modified | 2018-10-17 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 1147066 |
| File SHA-256 | 263b3d00d8e9611ceb178966e7ea64e16e57740aaa126e035133f18ec61415c3 |
| PDF Metadata Author | rachel |
| PDF Metadata Producer | rachel Acrobat Distiller 11.0 (Windows) |
| FCC.gov Sources | FCC.gov 4037404 |
