WM47A Wireless Microphone Transmitter Test... - FCC ID DBZWM47A
FCC ID DBZWM47A
Setup Photos
Wireless Microphone Transmitter
Document preview loads when visible.
Document Details
| FCC ID | DBZWM47A |
|---|---|
| Document ID | 4021643 |
| Document Type | Test Setup Photos |
| Description | Setup Photos |
| Document Title | Test Setup Photos |
| Applicant | Lectrosonics Inc |
| Equipment Class | Wireless Microphone Transmitter |
| Product Code | WM47A |
| Application ID | wOgebl3ekeUe3QKyiwOKdg== |
| Application Purpose | Original Equipment |
| Application Date | 2018-09-27 |
| Frequency Range | 470.1-495.675 MHz |
| FRN | 0007067481 |
| Test Firm | Bay Area Compliance Laboratories Corporation |
| Certified By | Robert Cunnings |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 03/25/2019 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2018-09-27 |
| Available | 2019-03-25 |
| Created | 2018-09-27 |
| Modified | 2018-09-27 |
| Pages | 2 |
| File Type | Adobe Acrobat PDF |
| File Size | 1386378 |
| File SHA-256 | b813d8a837a10e7bb5eb7a08b8646325a24fe0b6f563b78dfb5e3dfae38845dc |
| PDF Metadata Author | daniel |
| PDF Metadata Producer | daniel Acrobat Distiller 10.1.16 (Windows) |
| FCC.gov Sources | FCC.gov 4021643 |
