FRS168 14-Channel FRS Transceiver Operational... - FCC ID DRWFRS168
FCC ID DRWFRS168
Technical Description
14-Channel FRS Transceiver
Document preview loads when visible.
Document Details
| FCC ID | DRWFRS168 |
|---|---|
| Document ID | 125161 |
| Document Type | Operational Description |
| Description | Technical Description |
| Applicant | Eagletron Telecommunications Ltd |
| Equipment Class | 14-Channel FRS Transceiver |
| Product Code | FRS168 |
| Application ID | Z/s/a/HECtlFriHV9Z8GZA== |
| Application Purpose | Original Equipment |
| Application Date | 2001-01-22 |
| Frequency Range | 462.563-467.713 MHz |
| FRN | 0003786449 |
| Test Firm | Intertek Testing Services Hong Kong |
| Certified By | Wilson Loke Manager / ETL SEMKO - OP |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2000-11-13 |
| Available | 2001-01-22 |
| Created | 2000-11-13 |
| Modified | 2000-11-13 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 103376 |
| File SHA-256 | 479c27749e351113eadbf3df5f2fe5570ea06ecbbaf36e45a7507ecce63f77fb |
| PDF Metadata Producer | Acrobat 4.0 Scan Plug-in for Windows Acrobat 4.0 Scan Plug-in for Windows |
| FCC.gov Sources | FCC.gov 125161 |
