TFY3998R Parent's Unit of 900MHz Baby... - FCC ID DRWTFY3998R

FCC ID DRWTFY3998R

Block Diagram

Parent's Unit of 900MHz Baby Monitor

by Eagletron Telecommunications Ltd

Document preview loads when visible.

Document Details

FCC IDDRWTFY3998R
Document ID295260
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantEagletron Telecommunications Ltd
Equipment ClassParent's Unit of 900MHz Baby Monitor
Product CodeTFY3998R
Application IDIj8ky7iTkvr3QCzYVuXhxQ==
Application PurposeOriginal Equipment
Application Date2003-01-10
Frequency Range905.8-906.4 MHz
FRN0003786449
Test FirmIntertek Testing Services Hong Kong
Certified ByTommy Leung Assistant Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-01-10
Available2003-01-10
Created2002-11-25
Modified2002-11-25
Pages1
File TypeAdobe Acrobat PDF
File Size30135
File SHA-256ff1d02be8bff63b3cf79f7c2463a27da4eecdaddec80dff6ad94a70134809164
PDF Metadata ProducerAcrobat 5.0 Image Conversion Plug-in for Windows Acrobat 5.0 Image Conversion Plug-in for Windows
FCC.gov SourcesFCC.gov 295260
