Home automation gateway module

by Somfy Systems

Document preview loads when visible.

Document Details

FCC IDDWNBEECONPCB
Document ID4698127
Document TypeTest Setup Photos
DescriptionTest setup photo - DWNBEECONPCB
Document Title1 CONDUCTED AND RADIATED MEASUREMENT PHOTO
ApplicantSomfy Systems
Equipment ClassHome automation gateway module
Product CodeBEECONPCB
Application IDvAgAsgjngp70VkpVlSHzxg==
Application PurposeOriginal Equipment
Application Date2020-05-13
Frequency Range433.42 MHz
FRN0006579940
Test FirmLCIE Etablissement Sud-Est
Certified ByJim Hellander Engineering Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2020-04-22
Available2020-05-13
Created2020-03-25
Modified2020-03-25
Pages3
File TypeAdobe Acrobat PDF
File Size297058
File SHA-2567e47b22d7c6a4f58f19475c3dd01750512e31fbfed1a01a4b9ea2b4728a508f2
PDF Metadata AuthorPierre SELVA
PDF Metadata ProducerMicrosoft® Word 2013 Microsoft® Word 2013
FCC.gov SourcesFCC.gov 4698127, FCC.gov 4698114
