FCC ID E2K-DWRFID1601
RFID13.56MHz Wireless Module
by Dell Inc.
Grantee Code: E2K Product Code: DWRFID1601
Latest application date: 2018-10-23
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 13.56 MHz | Class II permissive change or modification of presently authorized equipment | 2018-10-23 |
| 13.56 MHz | Original Equipment | 2016-06-07 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual-1 | Users Manual | 2018-10-25 | PDF 1.3 MB |
| User Manual-2 | Users Manual | 2018-10-25 | PDF 1.3 MB |
| User Manual-3 | Users Manual | 2018-10-25 | PDF 1.3 MB |
| User Manual-4 | Users Manual | 2018-10-25 | PDF 540.3 KB |
| User Manual-5 | Users Manual | 2018-10-25 | PDF 75.7 KB |
| Users Manual (P18T) | Users Manual | 2016-06-21 | PDF 802.1 KB |
| Users Manual (P45G) | Users Manual | 2016-06-21 | PDF 726.4 KB |
| Users Manual (P46G) | Users Manual | 2016-06-21 | PDF 736.1 KB |
| Users Manual (module)_rev 2 | Users Manual | 2016-06-21 | PDF 72.7 KB |
| Users Manual_Warranty_Safety_Regulatory Information | Users Manual | 2016-06-21 | PDF 540.3 KB |
| Internal Photo | Internal Photos | 2018-10-25 | PDF 1.3 MB |
| Internal photos module | Internal Photos | 2016-06-21 | PDF 866.8 KB |
| Internal photos system | Internal Photos | 2016-06-21 | PDF 4.6 MB |
| External Photo | External Photos | 2018-10-25 | PDF 1.3 MB |
| External photos module | External Photos | 2016-06-21 | PDF 586.8 KB |
| External photos system | External Photos | 2016-06-21 | PDF 5.4 MB |
| Label and Location | ID Label/Location Info | 2018-10-23 | PDF 33.2 KB |
| Label Location (system-P18T) | ID Label/Location Info | 2016-06-07 | PDF 192.2 KB |
| Label Location (system-P45G) | ID Label/Location Info | 2016-06-07 | PDF 190.8 KB |
| Label Location (system-P46G) | ID Label/Location Info | 2016-06-07 | PDF 197.6 KB |
| Label format module | ID Label/Location Info | 2016-06-07 | PDF 585.2 KB |
| Label format system | ID Label/Location Info | 2016-06-07 | PDF 140.7 KB |
| Label location module | ID Label/Location Info | 2016-06-07 | PDF 122.6 KB |
| Setup Photo | Test Setup Photos | 2018-10-25 | PDF 739.9 KB |
| Test Set Up Photo (NFC)_rev | Test Setup Photos | 2016-06-21 | PDF 384.9 KB |
| Test Set Up Photo (RFID)_rev | Test Setup Photos | 2016-06-21 | PDF 385.3 KB |
| Test Report | Test Report | 2018-10-23 | PDF 1.7 MB |
| Test Report (NFC)_rev 2 | Test Report | 2016-06-07 | PDF 422.6 KB |
| Test Report (RFID)_rev 2 | Test Report | 2016-06-07 | PDF 423.1 KB |
| Justification of Labelling | Attestation Statements | 2016-06-07 | PDF 274.4 KB |
| C2PC declaration letter | Cover Letter(s) | 2018-10-23 | PDF 139.7 KB |
| Cover Letter | Cover Letter(s) | 2018-10-23 | PDF 276.2 KB |
| POA-1 | Cover Letter(s) | 2018-10-23 | PDF 24.7 KB |
| POA-2 | Cover Letter(s) | 2018-10-23 | PDF 119.5 KB |
| STCR letter | Cover Letter(s) | 2018-10-23 | PDF 454.7 KB |
| Agent authorization 1 of 2 | Cover Letter(s) | 2016-06-07 | PDF 242.3 KB |
| Agent authorization 2 of 2 | Cover Letter(s) | 2016-06-07 | PDF 30 KB |
| Request for confidentiality | Cover Letter(s) | 2016-06-07 | PDF 637.4 KB |
| Request for modular approval | Cover Letter(s) | 2016-06-07 | PDF 58 KB |
| Block diagram Metadata only | Block Diagram | PDF 206.5 KB | |
| Schematics Metadata only | Schematics | PDF 196.7 KB | |
| Antenna specification Metadata only | Operational Description | PDF 101.9 KB | |
| Operational Description Metadata only | Operational Description | PDF 318.7 KB | |
| Parts list Metadata only | Parts List/Tune Up Info | PDF 233.1 KB |
Application Information
| Application ID | Ij5NE7i8K6GHrE4BdttkFA== |
|---|---|
| Final Action Date | 2018-10-23 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0008359580 |
| Model | DWRFID1601 |
| Frequency Range | 13.56 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | RFID13.56MHz Wireless Module |
| Responsible Party | Don A Bobo, Distinguished Member of Technical Staff, don_bobo@dell.com  , 512-728-5508 |
| Test Firm | Ryan Wang, SGS Taiwan Ltd., Ryan-ec.wang@sgs.com  , +886-2-2299-3279 |
| TCB Email | stuart.beck@nemko.com  |
| TCB Scope | A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 10/25/2018 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited modular approval. Approval is for OEM installed only in Dell laptop model P45G, P18T and P46G. This device cannot be sold to the general public or installed by the end user. Class II Permissive Change: to address the module in new hosts of DELL, model number: P85G, P85G001, P86G/P86G001, as documented in this filing. |
