DWRFID230501 RFID 13.56MHz Wireless... - FCC ID E2K-DWRFID2305-01

FCC ID E2K-DWRFID2305-01

Test Setup Photos

RFID 13.56MHz Wireless Module

by Dell Inc.

Document preview loads when visible.

Document Details

FCC IDE2K-DWRFID2305-01
Document ID7098268
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitleNone
ApplicantDell Inc.
Equipment ClassRFID 13.56MHz Wireless Module
Product CodeDWRFID230501
Application IDMKVivfaMrxx66Q+xmkVlZg==
Application PurposeClass II Permissive Change
Application Date2024-02-05
Frequency Range13.56 MHz
FRN0008359580
Test FirmBureau Veritas CPS (H.K.) Ltd., Taoyuan Branch
Certified ByTilly Pan Specialist
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date08/04/2024
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2024-02-01
Available2024-08-04
Created2023-12-08
Modified2023-12-08
Pages3
File TypeAdobe Acrobat PDF
File Size397495
File SHA-256f4ac85ab88eae80a0e8b70b41bacc0084c1c2c7690ff040ca600ce68f4742548
PDF Metadata AuthorNone
PDF Metadata CreatorMicrosoft Word 2019
PDF Metadata ProducerMicrosoft Word 2019
FCC.gov SourcesFCC.gov 7098268
