  4. Test Report Photo 1

G8C214M G8C-214M Test Report - FCC ID E4EG8C-214M

FCC ID E4EG8C-214M

Test Report Photo 1

G8C-214M

by Omron Corporation

Test Report Photo 1

Document Details

FCC IDE4EG8C-214M
Document ID63487
Document TypeTest Report
DescriptionTest Report Photo 1
ApplicantOmron Corporation
Equipment ClassG8C-214M
Product CodeG8C214M
Application IDQn0nl4OUpt2NHVVtuMl56g==
Application PurposeOriginal Equipment
Application Date2000-11-01
Frequency Range315 MHz
FRN0006263933
Test FirmUL Japan, Inc.
Certified ByYoshiyuki Takahashi Deputy Manager of 2nd Division
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted1999-10-13
Available2000-11-01
Pages0
File TypeJPEG Image
File Size202954
File SHA-25630fffc2d40eb31ade41ccb8c37ebbded16ec539b9b844fa43bbd9fc5050c999b
FCC.gov SourcesFCC.gov 63487
