00220 Edge Panel (Bluetooth, WiFi, LTE, Z-wave... - FCC ID EF400220

FCC ID EF400220

Label&location

Edge Panel (Bluetooth, WiFi, LTE, Z-wave and SUB GHz transmitters)

by Nortek Security & Control LLC

Document preview loads when visible.

Document Details

FCC IDEF400220
Document ID5313134
Document TypeID Label/Location Info
DescriptionLabel&location
ApplicantNortek Security & Control LLC
Equipment ClassEdge Panel (Bluetooth, WiFi, LTE, Z-wave and SUB GHz transmitters)
Product Code00220
Application IDzp8/nulO/ftnP9agGHZ4sw==
Application PurposeOriginal Equipment
Application Date2021-06-28
Frequency Range1710.7-1754.3 MHz
FRN0006674840
Test FirmShenzhen Morlab Communications Technology Co. Ltd.
Certified ByWendy Zhan
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date12/26/2021
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-06-28
Available2021-06-28
Created2021-06-21
Modified2021-06-21
Pages1
File TypeAdobe Acrobat PDF
File Size182780
File SHA-25637a236abdbed7b4fdfc8e6546f5804281518c8ece5a65f7bff53a50d41d23f5a
PDF Metadata AuthorAdministrator
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 5313134, FCC.gov 5313038, FCC.gov 5312991, FCC.gov 5312937, FCC.gov 5312917
