DXS14 Security Alarm Transmitter Teardown... - FCC ID EF4DXS14

FCC ID EF4DXS14

Internal Photos

Security Alarm Transmitter

by Nortek Security & Control LLC

Document preview loads when visible.

Document Details

FCC IDEF4DXS14
Document ID1725056
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleDXS14_FCC_REV_Bx
ApplicantNortek Security & Control LLC
Equipment ClassSecurity Alarm Transmitter
Product CodeDXS14
Application IDDo8kiRaNNjLhSLtaxi/4JQ==
Application PurposeOriginal Equipment
Application Date2012-06-18
Frequency Range433.92 MHz
FRN0006674840
Test FirmLinear LLC
Certified ByJohn Kuivinen Regulatory Compliance Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2012-06-18
Available2012-06-18
Created2012-03-29
Modified2012-03-29
Pages3
File TypeAdobe Acrobat PDF
File Size672696
File SHA-2566ecaa71ff2bea60a162197ece19c476ac8a1c55bafaa9972d7f233cb3790a782
PDF Metadata Authorjohnk
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 8.1.0 (Windows)
FCC.gov SourcesFCC.gov 1725056
