BTM210 Bluetooth Radio Module Label Diagram - FCC ID EHABTM210

FCC ID EHABTM210

Host Label

Bluetooth Radio Module

by Intermec Technologies Corporation

Document preview loads when visible.

Document Details

FCC IDEHABTM210
Document ID380503
Document TypeID Label/Location Info
DescriptionHost Label
Document TitleC:\ and Settings\ccronin\\Projects\730\In release\073569.A\ARTMASTER\chop_chop_vendor.ai
ApplicantIntermec Technologies Corporation
Equipment ClassBluetooth Radio Module
Product CodeBTM210
Application IDivl7y7VzDlMIvxrg7Or2Zg==
Application PurposeOriginal Equipment
Application Date2003-12-11
Frequency Range2400-2483.5 MHz
FRN0022970339
Test FirmTUV SUD Product Service
Certified ByScott J Holub Regulatory Compliance Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2003-12-11
Available2003-12-11
Created2003-10-29
Modified2003-11-10
Pages1
File TypeAdobe Acrobat PDF
File Size381903
File SHA-256b8b335e82e375ef8bcd39d4c811d8205a38c82d291dc6138e882f2db93a36848
PDF Metadata ProducerAdobe Illustrator(R) 10.0 Adobe PDF library 5.00
FCC.gov SourcesFCC.gov 380503
