MT1A Car Alarm Transmitter Schematics - FCC ID ELVMT1A
FCC ID ELVMT1A
Schematic diagram
Car Alarm Transmitter
Document preview loads when visible.
Document Details
| FCC ID | ELVMT1A |
|---|---|
| Document ID | 202598 |
| Document Type | Schematics |
| Description | Schematic diagram |
| Applicant | Nutek Corporation |
| Equipment Class | Car Alarm Transmitter |
| Product Code | MT1A |
| Application ID | 0hYQDSBG5hV9IkQPn72FDQ== |
| Application Purpose | Original Equipment |
| Application Date | 2001-12-27 |
| Frequency Range | 302 MHz |
| FRN | 0016907594 |
| Test Firm | Compliance Engineering Services |
| Certified By | Rick Yeo EMC Manager ( AGENT ) |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2001-12-27 |
| Available | 2001-12-27 |
| Created | 2001-12-20 |
| Modified | 2001-12-20 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 111923 |
| File SHA-256 | b2ae6be1d030976ac322ac8f9e3969fef1ae78f01d146ba2f5218579ef272425 |
| PDF Metadata Producer | Acrobat Distiller 4.0 for Windows |
| FCC.gov Sources | FCC.gov 202598 |
