FCC ID EP9TMXM850
Component Side 2 of 3
Speed and Distance Monitor
Document Details
| FCC ID | EP9TMXM850 |
|---|---|
| Document ID | 235528 |
| Document Type | Internal Photos |
| Description | Component Side 2 of 3 |
| Applicant | Timex Group USA, Inc. |
| Equipment Class | Speed and Distance Monitor |
| Product Code | TMXM850 |
| Application ID | GJhOijQ8M6/5FY9uYnOpPQ== |
| Application Purpose | Original Equipment |
| Application Date | 2002-04-08 |
| Frequency Range | 0.138-0.141 MHz |
| FRN | 0023039423 |
| Test Firm | UL LLC |
| Certified By | David E. Born Test Engineer |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2002-04-09 |
| Available | 2002-04-08 |
| Pages | 0 |
| File Type | JPEG Image |
| File Size | 80391 |
| File SHA-256 | 8d2e92f8ca4d8156485948ed3ac3ab7d7a9a3e4a87faa8a5286cd0ffb522ff41 |
| FCC.gov Sources | FCC.gov 235528 |
