Document Details
| FCC ID | EUIT2X40 |
|---|---|
| Document ID | 35810 |
| Document Type | Schematics |
| Description | 5 |
| Document Title | 35810 |
| Applicant | Tally Computerdrucker GmbH |
| Equipment Class | T2X40 |
| Product Code | T2X40 |
| Application ID | r89cPUYQZc5c/MTk/oNl1w== |
| Application Purpose | Class II Permissive Change |
| Application Date | 1999-05-17 |
| FRN | 0004268603 |
| Certified By | Walter Boehm Certification Administrator |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | Yes |
| Submitted | 1999-05-04 |
| Available | 1999-05-17 |
| Created | 2001-06-24 |
| Modified | 2001-06-24 |
| Pages | 14 |
| File Type | Adobe Acrobat PDF |
| File Size | 434856 |
| File SHA-256 | 80b3c4aaf1f5d12ee89a88502b24ea4eb36fe4cc3c4895615c3c914dffb8d7c6 |
| PDF Metadata Author | VicodinES /CB /TNN |
| PDF Metadata Producer | Acrobat Distiller 4.0 for Windows |
| FCC.gov Sources | FCC.gov 35810 |
