DWMW077E WLAN 11b/g/n Module Test Report - FCC ID EW4DWMW077E

FCC ID EW4DWMW077E

FCC Report

WLAN 11b/g/n Module

by Mitsumi Electric Co Ltd

Document preview loads when visible.

Document Details

FCC IDEW4DWMW077E
Document ID2484900
Document TypeTest Report
DescriptionFCC Report
Document Title10548959S_FCC15C
ApplicantMitsumi Electric Co Ltd
Equipment ClassWLAN 11b/g/n Module
Product CodeDWMW077E
Application IDQSw2OF9on7srf/2lyZ+7nw==
Application PurposeOriginal Equipment
Application Date2014-12-26
Frequency Range2412-2462 MHz
FRN0006990816
Test FirmUL Japan, Inc. Shonan EMC EMC Lab.
Certified ByYoshihisa Maeda Project Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2014-12-26
Available2014-12-26
Created2014-12-16
Modified2014-12-26
Pages66
File TypeAdobe Acrobat PDF
File Size2575663
File SHA-256341d6963ff2a2e5d4f270e1baddec1d83942996e8a3324b2764f940eebf79043
PDF Metadata Author38775
PDF Metadata ProducerAcrobat Distiller 10.1.2 (Windows) 38775
FCC.gov SourcesFCC.gov 2484900
