805299B00 900 MHz/2.4 GHz Cordless Phone... - FCC ID EW780-5299-B00
FCC ID EW780-5299-B00
Block Diagram
900 MHz/2.4 GHz Cordless Phone
Document preview loads when visible.
Document Details
| FCC ID | EW780-5299-B00 |
|---|---|
| Document ID | 306479 |
| Document Type | Block Diagram |
| Description | Block Diagram |
| Document Title | 2434theory0 |
| Applicant | VTech Telecommunications Ltd |
| Equipment Class | 900 MHz/2.4 GHz Cordless Phone |
| Product Code | 805299B00 |
| Application ID | voWi8rQ55ZT18ReMKFoAUA== |
| Application Purpose | Original Equipment |
| Application Date | 2003-02-27 |
| Frequency Range | 2410.2-2418.9 MHz |
| FRN | 0015973951 |
| Test Firm | Bay Area Compliance Laboratory |
| Certified By | Charles Yu Engineer Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2003-02-28 |
| Available | 2003-02-27 |
| Created | 2003-02-28 |
| Modified | 2003-02-28 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 168061 |
| File SHA-256 | 367e3c878b2382f89f2fcf91c97da0d4c9663cd79013a4758616698a66ff71f3 |
| PDF Metadata Author | nrd96163 |
| PDF Metadata Producer | ADOBEPS4.DRV Version 4.50 Acrobat Distiller 5.0 (Windows) |
| FCC.gov Sources | FCC.gov 306479 |
