DEI474S Sidewinder Transmitter Block Diagram - FCC ID EZSDEI474S

FCC ID EZSDEI474S

block diagram

Sidewinder Transmitter

by Voxx Electronics Corporation

Document preview loads when visible.

Document Details

FCC IDEZSDEI474S
Document ID299987
Document TypeBlock Diagram
Descriptionblock diagram
Document Title3
ApplicantVoxx Electronics Corporation
Equipment ClassSidewinder Transmitter
Product CodeDEI474S
Application IDDT8q37xecEFBXmc8mMduyw==
Application PurposeOriginal Equipment
Application Date2003-03-14
Frequency Range433.92 MHz
FRN0006819940
Test FirmTUV America
Certified ByJim Owen Engineer in Charge
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2003-01-30
Available2003-03-14
Created2003-01-20
Modified2003-01-20
Pages1
File TypeAdobe Acrobat PDF
File Size15668
File SHA-2564fb3c1be01ac5bf0ae09fe6ac52c51b034b3bd6dc2a677e13eb9d99d24851b2a
PDF Metadata Authorjevans
PDF Metadata ProducerDocument3 - Microsoft Word Acrobat PDFWriter 4.05 for Windows NT
FCC.gov SourcesFCC.gov 299987
